(31/104)
Item
OP code
page
OP code Parameter Remarks
MULTI INPUT
INPUT DETECT 02h 40h 0: FIRST DETECT
1: LAST DETECT
2: NONE
3: VIDEO DETECT
4: CUSTOM DETECT
CUSTOM DETECT
PRIORITY1 10h 2Eh 0: No mean
1: VGA(RGB)
5: VIDEO
12(0Ch): YGA(YPbPr)
15(0Fh): DisplayPort
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
135(87h): MP
PRIORITY2 10h 2Fh
PRIORITY3 10h 30h
TERMINAL SETTING
VGA MODE 10h 8Eh 0: No mean
1: RGB
2: YPbPr
DisplayPort BITRATE 11h 19h 0: No mean
1: RBR
2: HBR
VIDEO LEVEL 10h 40h 0: No mean
1: EXPAND
2: NORMAL
HDMI / DisplayPort
MODE
11h B1h
0: No mean
1: RGB
2: YUV
3: AUTO
RESET
(MULTI INPUT)
02h CBh 0: No mean
6: Reset MULTI INPUT
Category
Momentary
OSD
LANGUAGE 00h 68h 0: No mean
1: ENGLISH
2: GERMAN
3: FRENCH
4: SPANISH
5: JAPANESE
6: ITALIAN
7: SWEDISH
9: RUSSIAN
14(0Eh): CHINESE
OSD Language
MENU DISPLAY TIME 00h FCh 0-1: Do not set.
2: 10s
3: 15s
|
48(30h): 240s
5sec/step
OSD POSITION 00h EFh 0: CENTER
1: UP LEFT
2: UP RIGHT
3: DOWN LEFT
4: DOWN RIGHT
INFORMATION OSD 02h 3Dh 0:Disable information OSD
3-10(0Ah):
OSD timer [seconds]
OSD ROTATION 02h 41h 0: Landscape
1: Rotated
KEY GUIDE 11h 7Ah 0: No mean
1: OFF
2: ON
MEMO 10h BAh 0: No mean
1: Display a Memo
2: Undisplay a Memo
INPUT NAME Refer to chapter 18
NAME RESET
