GRAPHITE 59G063 [22/184] Operation adjustments

• Remove a previously installed working tool, if it is installed.

• Both ﬂanges should be removed before installation – the inner ﬂange (6) and outer ﬂange (5).

• Put the threaded part of a working tool onto the spindle and slightly tighten.

Working tools with threaded holes are removed in the reverse order.

INSTALLING THE ANGLE GRINDER ON A TRIPOD FOR ANGLE GRINDERS

The angle grinder can be used on a dedicated tripod for angle grinders, provided that it is correctly installed

according to instructions of the manufacturer of a tripod.

OPERATION / ADJUSTMENTS

Before the grinder is used, check condition of the grinding wheel. Do not use chipped, broken or

otherwise damaged grinding wheels. Worn grinding wheel or brush should be immediately replaced

with new one before use. Once your work is completed, you should switch o the grinder and wait

until it comes to a complete stop. Only then the grinder can be put aside. Do not brake a rotating

grinding wheel by pressing it against a workpiece.

• Do not overload the grinder. The weight of the power tool exerts sucient pressure to eciently

work with the tool. Overloading and excessive pressure may lead to dangerous cracking of the

working tool.

• If the grinder is dropped during operation, it should be checked and a working tool might need to

be replaced, when it is damaged or deformed.

• Never strike the workpiece with a working tool.

• Do not use the grinding wheel for hammering or stripping of the workpiece, especially when corners,

sharp edges are worked, etc. (this may cause loss of control of the power tool and recoil).

• Do not use discs from circular saws intended for wood cutting. Failure to observe this recommendation

may result in recoil of the power tool, loss of control and may lead to injuries of the operator.

SWITCHING ON /SWITCHING OFF

When the grinder is switched on and operated, it should be held with both hands.

• Press the rear part of the switch (2).

• Move the switch (2) forwards - (towards the head) (g. C).

• Press the front part of the switch for continuous operation.

• The switch will be automatically locked in the position for continuous operation.

• Press the rear part of the switch (2) to switch the tool oﬀ.

Once the grinder is switched on, wait until the grinding wheel reaches maximum speed and only

then you can begin to work. During operation do not use the switch to switch the grinder on and o.

The grinder switch can be used only when the power tool is moved away from the workpiece.

The tool is equipped with a switch with undervoltage release feature. In case of temporary mains

power failure or connecting to mains socket with switch in ON position, the tool will not start. In such

case move the switch to OFF position and switch it on again.

CUTTING

• The angle grinder can be used for cutting in a straight line only.

• Do not cut a workpiece holding it in your hands.

• Large workpiece should be supported. Make sure the support points are located near the cutting line

and at the ends of the workpiece. A stably located workpiece will not tend to move, when it is cut.

• Small workpieces should be fastened in a vice or using clamps, for example. The workpiece should

be fastened so that it is cut near the fastening element. This will ensure higher cutting precision.

• Do not allow the cut-o wheel to vibrate or jump, since this will lower the quality of cutting and

may cause the cut-o wheel to break.

• Do not exert lateral pressure onto the cut-o wheel during cutting.

• A proper cut-o wheel should be used depending on a workpiece type.

• When a workpiece is cut, it is recommended that a cutting direction is the same as rotation direction

of the cut-o wheel.

GRAPHITE 59G063 [22/184] Operation adjustments
