safety measures reduce the risk of starting the power tool accidentally.
d)
Store idle power tools out of the reach of children and do not allow per-
sons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tools operation. If damaged, have the power tool repaired by a
qualified expert or by an authorised REMS after-sales service facility
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Secure the workpiece. Use clamps or a vice to hold the workpiece. This
is safer than holding it with your hand, and also it frees both hands to ope-
rate the equipment.
h) Use the power tool, accessories and tool bits etc., in accordance with
these instructions and in the manner intended for the particular type
of power tool, taking into account the working conditions and the work
to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation. All unauthorised modifica-
tions to the power tool are prohibited for safety reasons.
E) Battery tool use and care
a) Ensure the switch is in the off position before inserting battery pack.
Inserting the battery pack into power tools that have the switch on invites
accidents.
b) Recharge only with the charger specified by the manufacturer. A char-
ger that is suitable for one type of battery may create a risk of fire when used
with another battery pack.
c) Use battery tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
d) When battery pack is not in use, keep it away from other metal objects
like paper clips, coins, keys, nails, screws, or other small metal objects
that can make a connection from one terminal to another. Shorting the
battery terminals may cause bums or a fire.
e) Under abusive conditions, liquid may be ejected from the battery, avo-
id contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or bums.
f) Do not use the battery/charger at battery/charger temperatures or am-
bient temperatures of 5°C/40°F or b 40°C/105°F.
g) Do not dispose defective batteries in the normal domestic waste. Take
them to an authorised REMS after-sales service facility or to a repu-
ted waste disposal company.
F) Service
a) Have your power tool serviced by a qualified repair person using on-
ly identical replacement parts. This will ensure that the safety of the po-
wer tool is maintained.
b) Comply with maintenance instructions and instructions on tool re-
placements.
c) Check mains lead of power tool regularly and have it replaced by a
qualified expert or an authorised REMS after-sales service facility in
case of damage. Check extension cable regularly and replace it when
damaged.
Specific Safety Instructions
•
Wear gloves suitable against cold temperatures.
•
Ice causes burns upon contact with skin. After work is finished, let deep-
freezer heads thaw out.
•
Do not bend or twist hoses or subject them to tensile stress. This can lead
to leaks.
•
Do not open up the refrigerant circuit. The apparatus contains the refri-
gerant R 404A in a closed circuit. Should refrigerant leak out in the event
of defective apparatus (e.g. breakage of a refrigerant hose), then the follo-
wing must be taken into consideration:
– Do not inhale: Get those affected into the fresh air and let them rest.
Should their breathing stop, use artificial respiration and call a physician.
– After contact with the skin: Thaw out or wash off affected portions of
skin with warm water.
– After contact with eyes: Rinse out thoroughly for 10 minutes with clean
water; call a physician.
– After swallowing: Do not induce regurgitation. Wash out mouth with
water, drink a glass of water. Go to a physician.
– Notice for physician: Do not administer any drugs of the Ephedrine /
adrenalin group.
Attention:
In case of thermal decomposition of the refrigerant (e.g. fire)
highly noxious and corrosive vapours are generated.
•
Observe safety tips for refrigeration systems.
•
When scrapping the apparatus, dispose of the refrigerant properly.
•
Refrigerant may not be allowed to get into sewers, basements or work pits.
Refrigerant vapours may create a suffocating atmosphere.
1. Technical data
1.1. Article numbers
Deep freezer insert
1
/
8
”(10, 12 mm) (pair) 131110
Deep freezer insert 1
1
/
4
” (42 mm) (pair) 131155
Deep freezer insert 1
1
/
2
” (pair) 131156
Deep freezer insert 54 mm (pair) 131157
Deep freezer insert 2”(60 mm) (pair) 131158
LCD digital thermometer 131115
Tightening strap 131104
Water squirt bottle 093010
1.2. Working range
Deep freezing liquids of all kinds such as,
e.g. water, milk, beer in tubes of steel,
copper, cast iron, lead, aluminium,
plastic, etc
1
/
8
–2” or 10–60 mm
Ambient temperature +10°C up to +32°C
1.3. Electric data
Rated voltage, frequency, power, current
230 V~; 50 Hz, 430 W; 1.81 A
Safety class 1 Earthed conductor required
Safety type IP 33
1.4. Refrigerant data
Refrigerant R 404 A
Volume quantity 0.150 kg
Refrigerant circuit operating pressure max. 27 bar
1.5. Dimensions
Apparatus 310 × 305 × 360 mm
(12”×12”×14”)
Refrigerant hosing length 2 m
1.6. Weight
Apparatus 22.3 kg (50 lbs)
1.7. Noise information
Workplace-related emission reading 70 dB(A)
1.8. Vibrations
Weighted effective acceleration reading 2.5 m/s²
2. Preparations for Use
Deep freezing occurs by means of a transfer of refrigeration from the deep-
freezer heads to the outer surface of the tubing. To ensure good contact
transition, paint, rust or other pollutants should be removed from the tubing.
Deformed tubes cannot be frozen up.
The water (or other liquid) in the tubing can only freeze up if there is no flow,
i.e. pumps should be turned off, water removal should be avoided. Cool off
water in the heating tubes to ambient temperature before deep freezing.
2.1. Mounting of the deep freeze heads
With tube sizes
1
/
4
–1” resp. 14–35 mm the deep-freezer heads are placed
directly against the tube (Figure 1). Fasten deep-freezer heads with the tightening
strap (Figure 2). Shortest freezing times will be achieved when the hose
connector at the deep-freezer head is pointing upwards.
2.2. Using the deep freezer inserts
For tube sizes
1
/
8
”(10, 12 mm), 1
1
/
4
”(42 mm), 1
1
/
2
”, 54 mm, 2”(60 mm) deep-
freezer inserts (accessories) are required (Figure 1). The latter are placed in
the deep-freezer heads. Each application can be seen in the table (Fig. 3). Fa-
sten deep-freezer heads with deep-freezer inserts to the tube with the tigh-
tening strap (Figure 2).
3. Operation
Turn the apparatus on only if the deep-freezer heads have been mounted. For
improving refrigeration transfer from the deep freezer heads to the tube, during
