English | 21

Bosch Power Tools 1 619 929 J21 | (21.6.11)

20 Laser warning label

21 Warning label, laser radiation exit opening

(GRL 300 HV/GRL 300 HVG)

22 Battery charger*

23 Mains plug of the battery charger*

24 Charge connector*

Remote control

25 Button on the remote control for rotation operation and

selection of rotational speed

26 Button on the remote control for line operation and se-

lection of line length

27 Shock-warning reset button

28 Button for “rotation in clockwise direction”

29 Button for “rotation in anticlockwise direction”

30 Operation indicator

31 Outlet opening for infra-red beam

32 Serial number

33 Latch of battery lid

34 Battery lid

Accessories/Spare parts

35 Laser receiver*

36 Construction laser measuring rod*

37 Tripod*

38 Laser viewing glasses*

39 Wall mount/alignment unit*

40 Fastening screw of the wall mount*

41 Screw of the alignment unit*

42 5/8" screw on wall mount*

43 Laser target plate*

44 Ceiling measurement plate*

45 Case

* The accessories illustrated or described are not included as

standard delivery.

Technical Data

Rotational Laser Level GRL 250 HV

Professional

GRL 300 HV

Professional

GRL 300 HVG

Professional

Article number

3 601 K61 60. 3 601 K61 50. 3 601 K61 70.

Working range (radius)

– without laser receiver, approx.

– with laser receiver, approx.

30 m

125 m

30 m

150 m

50 m

150 m

Levelling Accuracy

1) 2)

± 0.1 mm/m ± 0.1 mm/m ±0.1 mm/m

Self-levelling range, typically

±8% (±5°) ±8% (±5°) ±8% (± 5°)

Levelling duration, typically

15 s 15 s 15 s

Rotational speed

150/300/600 min

-1

150/300/600 min

-1

150/300/600 min

-1

Aperture angle for line operation 10/25/50° 10/25/50° 10/25/50°

Operating temperature

–10...+50 °C –10...+50 °C 0...+40 °C

Storage temperature

–20...+70 °C –20...+70 °C –20...+70 °C

Relative air humidity, max.

90 % 90 % 90 %

Laser class

23R3R

Laser type

635 nm, <1 mW 635 nm, <5 mW 532 nm, <5 mW

Laser beam Ø at the exit opening,

approx.

5mm 5mm 5mm

Tripod mount (horizontal)

5/8"-11 5/8"-11 5/8"-11

Batteries (NiMH)

Batteries (alkali-manganese)

2 x 1.2 V HR20 (D) (9 Ah)

2 x 1.5 V LR20 (D)

2 x 1.2 V HR20 (D) (9 Ah)

2x1.5VLR20 (D)

2x1.2VHR20 (D) (9Ah)

2 x 1.5 V LR20 (D)

Operating life time, approx.

– Batteries (NiMH)

– Batteries (alkali-manganese)

40 h

60 h

30 h

50 h

20 h

30 h

Weight according to

EPTA-Procedure 01/2003

1.8 kg 1.8 kg 1.8 kg

Dimensions (length x width x height)

190 x 180 x 170 mm 190 x 180 x 170 mm 190 x 180 x 170 mm

Degree of protection

IP 54 (dust and splash

water protected)

IP 54 (dust and splash

water protected)

IP 54 (dust and splash

water protected)

1) at 20 °C

2) alongside the axes

Please observe the article number on the type plate of your rotational laser level. The trade names of individual rotational laser levels may vary.

For clear identification of your rotational laser level, see the serial number 19 on the type plate.
