4 First steps
10
Only .bmt and .bmp files and folder structures are
transferred.
1. Click on [Continue].
2. Highlight the folders or images to be transferred.
When a folder is marked, all subfolders are automatically included.
3. Click on [Continue].
4. Select the location you want to save them to:
• In the archive (only for images from imagers that support
site recognition, e.g. testo 885 / 890)
• In the file system (target directory must be specified).
> If required, activate the optional functions Set target directory
as default and Delete data in the device after copying.
5. Click on [Continue].
- When importing to the file system: In the selected target
directory, a folder is created with the date of the data transfer to
prevent the overwriting of previous folders with the same
designation. The folders and the images are saved in this
directory.
- When adding to the archive: the images are inserted into the
archive structure. Existing images are not overwritten.
6. Click on [Finish].
- The Import Wizard is closed.
Activating/deactivating the Import Wizard
> In IRSoft click on the Imager tab and carry out the desired
change in the Import Wizard group.
