Testo 875-1 [31/65] Histogram document window
![Testo 875-1 [31/65] Histogram document window](/views2/1394110/page31/bg1f.png)
6 Using the software
31
Function Procedure
Select Isotherm
colour
(only available with
activated isotherms)
> Click on Colour isotherms and select
a colour.
If Rainbow is selected, the isotherm is shown
in a rainbow colour palette. Temperature
gradings within the isotherm are thus
rendered visible.
If Rainbow is selected, we
recommend setting the colour palette
of the IR image to Greyscale.
6.4.3. Histogram document window
The following functions are available in the Histogram document
window:
• Saving a histogram as an image file
• Copying a histogram to the clipboard
• Choosing between absolute (number of the measurement
points) and relative (percent of the measurement points)
scaling:
• Setting the background colour for the histogram
• Switching grid lines in the histogram on/off
• Setting the number of columns over the temperature range
being assessed
Changes can only be seen if a histogram had already been
created in the Thermal image document window for the
infrared image currently open, see Creating a histogram
page 27.
Function Procedure
Saving a histogram as an
image file
1. Click on Save file .
- The Windows dialogue for saving
files is opened.
2. Enter a file name.
3. Select a file format (BMP, JPG,
PNG).
4. Select a storage location and click
on [Save].
