6 Using the software
15
6 Using the software
6.1. Performing program settings
Program settings can be performed on the Settings tab.
6.1.1. Modifying the work space view
Tabbed windows/overlapping windows
The work space view can be modified in the Settings tab.
1. In the ribbon, click on the Settings tab.
2. Modify the work space view in the Work space view group.
> For quick changes to the work space view: Click on (tabs)
or (overlapping windows) in the status bar.
Tab groups
Arranging the tabs into groups makes it easier to compare several
IR images.
Prerequisites:
• At least 2 IR images are open.
• The Tabbed windows work space view is open, see above.
1. Right-click on the tab of an infrared image that you wish to
compare with another infrared image.
- A context menu is opened.
2. From the context menu, select the option New Horizontal /
New Vertical Tab Group.
- The infrared image can be compared with the other infrared
image.
> If you wish to compare more than 2 images: Repeat the
procedure starting with step 3.
6.1.2. Image presentation
The image presentation can be optimized:
• Image smoothing: the image presentation is optimized by
means of an algorithm.
• Radial distortion correction (not available for images from
testo 880, testo 885, testo 890): compensates for the optical
distortion in images made with wide-angle lenses.
1. Click on the Settings tab.
2. Activate/deactivate the desired function under the Image
presentation group.
