6 Using the software
22
- If the result is unsatisfactory: Return to the Image markings tab
and optimize the marking points (moving, supplementing with
additional points)
The following functions are available to adjust the image overlay:
Setting transparency level
The Transparency level regulates the proportion of the infrared or
the real image in the overlay. The IR readings can even be read off
with the setting 100 % real image (no IR image visible).
> Click on the controller. Hold the mouse button down and move
the controller.
Setting infrared limit values
The observation area of the image overlay can be limited with the
infrared limit values. Only values above an upper limit value or
values below a lower limit value are shown as infrared image
information. Only the real image is shown in the irrelevant
temperature range.
With activated infrared limit values, setting the transparency
level to 100 % infrared is recommended. The relevant
temperature ranges are thereby most clearly visible.
Function Procedure
Activate Use upper
limit value or Use
lower limit value
> Activate the desired limit value .
Set Upper/lower
limit value
(only available with
activated limit
value)
> Click on the number and change it by
means of input via the keyboard or via .
or
> Click on the controller of the lower/upper
limit value. Hold the mouse button down
and move the controller.
Setting infrared range
The observation area of the image overlay can be limited with the
infrared range. Only values between the two range limits are shown
as infrared image information. Only the real image is shown in the
irrelevant temperature range.
With an activated infrared range, setting the transparency
level to 100 % infrared is recommended. The relevant
temperature range is thereby most clearly visible.
