Assembly

f Avoid unintentional starting of the machine. During as-

sembly and for all work on the machine, the power plug

must not be connected to the mains supply.

Delivery Scope

Please also observe the representation of the

delivery scope at the beginning of the operat-

ing instructions.

Before starting the operation of the machine

for the first time, check if all parts listed be-

low have been supplied:

– Table saw with mounted saw blade 26 and riving knife 25

– Angle stop 3

– Profile rail 28

– Fastening kit “profile rail” 40 (guide plate, knurled nut,

screw, washer)

– Parallel guide 10

– Auxiliary parallel guide 37

– “Auxiliary parallel guide” fastening kit 38 (3 fastening

screws, 3 washers, 3 wing nuts)

– Blade guard 6.x*

* depending on country version: 6.1/6.2

– Allen key 21

– Allen key 64

– Ring spanner 22

–Push stick 23

– Insert plate 24

– Extraction adapter 32

Note: Check the power tool for possible damage.

Before further use of the machine, check that all protective

devices are fully functional. Any lightly damaged parts must

be carefully checked to ensure flawless operation of the tool.

All parts must be properly mounted and all conditions fulfilled

that ensure faultless operation.

Damaged protective devices and parts must be immediately

replaced by an authorised service centre.

Mounting Individual Components

– Carefully remove all parts included in the delivery from

their packaging.

Remove all packaging material from the machine and the

accessories provided.

– Take care that the packaging material under the motor

block es removed.

The following product features are fastened directly to the

housing:

Push stick 23, ring spanner 22, allen key 21 and 64, parallel

guide 10, angle guide 3, extraction adapter 32, auxiliary par-

allel guide 37 with fastening kit 38, blade guard 6.x.

– Carefully remove these product features from their stor-

age locations.

Also see figures Y1–Y6.

Mounting the Insert Plate (see figure A)

– Hook insert plate 24 into the rear insert-plate notches 34

of the tool basin.

– Guide the insert plate down.

– Press on the insert plate until it engages at the front in the

tool basin.

The front side of the insert plate 24 must be flush with or

somewhat lower than the saw table; the rear side must be

flush with or somewhat above the saw table. (also see “Ad-

justing the Level of the Insert Plate”, page 36)

Mounting the Blade Guard* (see figure B)

* depending on country version

– Turn crank 19 clockwise to the stop, so that the saw blade

26 is in the highest possible position above the saw table.

– Pull the riving knife 25 upward to the stop.

– Insert the blade guard 6.x into the recess in riving knife 25.

– Tighten the clamping lever 8.1.

Tighten clamping screw 8.2 with Allen key 21.

– Adjust the blade guard according to the workpiece height.

When sawing, the blade guard must always face lightly

against the workpiece.

Note: Clamping lever 8.1 is indexed (adjustable), allowing it

to be set to an ergonomically favourable or space-saving posi-

tion.

With the clamping lever tightened, pull its lever away from the

blade guard, turn it to the desired position and allow it to en-

gage again.

Mounting the Parallel Guide (see figure C)

The parallel guide 10 can be positioned either left or right

from the saw blade.

– Loosen clamping handle 35 of parallel guide 10.

This releases V-guide 36.

– Firstly, mount the parallel guide via the V-guide in guide

groove

11 of the saw table. Now, position the parallel

guide into the front guide groove 2 of the saw table.

The parallel guide can now be moved to any position.

– To lock the parallel guide, press the clamping handle 35

down.

Mounting the Auxiliary Parallel Guide (see figure D)

When sawing narrow workpieces and bevel angles, the

auxiliary parallel guide 37 must be mounted to parallel guide

10.

The auxiliary parallel guide can be mounted left or right from

parallel guide 10, as required.

For assembly, use the “auxiliary parallel guide” fastening kit

38. (3 fastening screws, 3 washers, 3 wing nuts)

Dr. Egbert Schneider

Senior Vice President

Engineering

Dr. Eckerhard Strötgen

Head of Product

Certification
