48 381-131_v01
The reverse assembling of the mixers can
cause lifting up the dough (taking the dough
out of bowl).
The level of products inside the bowl should
not exceed the hight of mixers or whisks
working part (L).
Operation with liquidising disc
Liquidizing disc is used for liquidizing boiled fruit and
●
vegetables such as: carrots, potatoes, tomatoes, apples
through the sieve. It partly replaces the function of the
mixing adapter.
1
Insert the liquidizing disc on the whisk with toothed bar
from the bottom side.
2
Insert the whisk into the socket marked with a star.
Cup (12)
Made of transparent material is used as a container when
mixing adapter is used.
Operation with mixing adapter
You can use the mixing adapter for:
mixing liquids,
●
crumbling boiled vegetables and raw, soft fruit,
●
preparing different mayonnaise and pastes,
●
preparing soups for infants.
●
crushing ice (metal adapter only).
●
You can assemble the adapter after moving the cover.
1
Gently press the bolt and slide towards the direction
shown in the gure.
2
Insert the threaded part into the motor casing hole and
screw it turning right until you feel the refusal.
Inadequate screwing of the mixing adapter can
result in clutch damage or the adapter damage.
3
Put the adapter into the processed product and switch
the mixer on.
Operation with mixing cup
Hold the mixer in your hand all the time during
operation.
Mixing cup is intended for infant soups preparation, milk
shakes or pancake dough.
It has the label „500 ml max” on both sides, which
●
indicates the maximum level of product to ll the cup and
graphic scale to determine the volume 200 ml to 500 ml
(according to the symbols in the drawing beside).
1
After moving the cover (like during assembling the
adapter) assemble the cup the following way: Insert the
E
F
G
mixing cup on the motor part so that the 3 buckles visible at
the bottom of the cup got into the nuts of the motor casing.
2
Holding the motor casing handle turn the cup clockwise
direction until you feel the refusal.
You shall obtain the proper connection, when the 3 buckles get
under the motor casing, and the fastener on the cup rib move
on the other side of the spherical buckle on the motor casing.
3
Fill the cup with products and put the cover with the doser
on – you can add next products to the cup during operation.
Operation with stand including turnable bowl
The stand with assembled motor part makes the operation
with whisks or mixers easy, as the user does not have to hold
the device.
The stand head driver automatically makes the head move
pendulum-like and simultaneously turns the bowl with the
mixed product.
You can use the stand with specially prepared whisks and
mixers only. The device equipped with stand includes also
one mixer and one whisk with toothed bar.
1
Insert the mixers or whisks into the motor casing (as
described above).
2
Assemble the drive in the stand head after moving the
cover (like during assembling the adapter) the following way:
Insert the drive fasteners (which are located near the holes
for whisks assembling) under the stand head fastener.
3
Turn the control clamp to the limit in such a way that the
hand is positioned vertically.
4
Press the fastener button and simultaneously deect the
stand head with the motor part back.
5
If the bowl with products a bit up and then insert it on the
three insertions and place it at the stand base.
6
Place the stand head with the motor part in horizontal
position (you will hear the clicking sound of fastener blocking
clamps).
Start-up the mixer with the switch lever and it will make the
●
bowl turn and the head with drive move pendulum-like.
Never block or stop the oscillatory movement
during operation. It may cause damage to the
housing.
After operation
1
Switch the mixer off and unplug it.
Depending on assembled equipment:
2
Push the whisks or mixers out with a pushing button.
3
Disassemble the liquidizing disc from the whisk.
Disassemble the mixing adapter or mixing cup in reverse
●
way to assembling it.
4
Deect the stand head with the motor part back.
5
Turn the clamp knob in counter clockwise direction as
much as possible and put the motor out of the head fasteners.
6
Wind the power cord on the motor part and put the last
winding under the insert.
H
I
1 cm L 1 cm L
