Ref. Warning Risk SimboloSymbol

Fire due to overheating from

electrical current passing through

undersized cables

24 Make all electrical connections

using conductors with a suitable

section

Damage to the appliance or

surrounding objects from falling

splinters, knocks and incisions.

25 Protect the appliance and all

areas in the vicinity of the work

place using suitable material.

Damage to the appliance or sur-

rounding objects from shocks,

knocks, incisions and squashing.

27 Organise the dislocation of all

debris and equipment in such a

way as to make movement easy

and safe, avoiding any piles that

could yield or collapse.

Damage to the appliance or sur-

rounding objects from shocks,

knocks, incisions and squashing.

26 Handle the appliance with

suitable protection and with care.

Damage or shutdown of the

appliance due to out-of-control

operation.

28 Reset all the safety and control

functions affected by any inter

ventions performed on the appli

ance and make sure they operate

correctly before re-using the ap

pliance.

SPECIFIC SAFETY NORMS FOR THIS APPLIANCE

Key to symbols:

Failure to comply with this warning implies the risk of personal injury, in some

circumstances even fatal

Failure to comply with this warning implies the risk of damage, in some

circumstances even serious, to property, plants or animals.

Obligation to keep to the general safety norms and appliance specifications

Symbol Meaning

Ref. Warning Risk SimboloSymbol

Personal injury from burns.

29 Before handling, empty all

components that may contain

hot water, carrying out any

bleeding if necessary.

Personal injury due to contact of the

skin or eyes with acidic substances,

inhalation or swallowing of harmful

chemical agents.

Damage to the appliance or sur-

rounding objects due to corrosion

caused by acidic substances

30 Descale the components, in

accordance with the instructions

provided on the “safety data

sheet” of the product used, airing

the room, wearing protective

clothing, avoid mixing different

products, and protect the

appliance and surrounding

objects.

DESCRIPTION OF THE WATER HEATER (see fig. 1,2,3)

The packaging dimensions of the product and the description of the main components are shown in

figures 1,2,3

TECHNICAL CHARACTERISTICS

For the technical characteristics of the appliance, please refer to the information

provided on the data plate.

This appliance complies with the provisions set forth in the EEC/89/336 EMC directive on

electromagnetic compatibility.

150 150 200 200 300 300 300

ModelloModel 3kW 3kW 3kW 3kW 3kW 3kW 6kW

MT M T M T T

Capacity l see data plate

Current A see data plate

Voltage V~ see data plate

Power W see data plate

Water pressure MPa/bar see data plate

INSTALLATION NORMS (for the installer)

ATTENZIONE! Seguire scrupolosamente le avvertenze generali e le norme

di sicurezza elencate all’inizio del testo, attenendosi obbligatoriamente a

quanto indicato.

23 24
