Air Flow Data (continued)

VH 07 - Rectangular return / Rectangular discharge - Air flow (m

/h)

VH 07 - Rectangular return / Circular discharge - Air flow (m

/h)

VH 07 - Circular return / Circular discharge - Air flow (m

/h)

Speeds Filter

External static pressure (Pa)

0 25 50 75 95 100 105 110

Without 845 775 707 639 ----

G3810745679613----

G4798733671607----

Without 1030 970 908 831 750 - - -

G3 995 937 871 787 700 - - -

G4 975 919 853 768 682 - - -

Without 1300 1219 1150 1056 937 898 - -

G3 1250 1170 1093 979 836 791 - -

G4 1210 1137 1056 933 784 737 - -

Without 1730 1605 1490 1345 1180 1129 1074 -

G3 1615 1498 1372 1205 1020 965 905 -

G4 1525 1408 1282 1116 935 881 824 -

Without 2000 1848 1716 1559 1382 1328 1269 1205

G3 1845 1703 1558 1376 1180 1122 1059 991

G4 1711 1574 1432 1254 1065 1009 950 886

Speeds Filter

External static pressure (Pa)

0 25 50 75 95 100 105 110

Without 815 747 683 617 ----

G3785720658592----

G4771709650585----

Without 995 938 873 790 705 - - -

G3 965 906 836 747 654 - - -

G4 945 887 818 728 638 - - -

Without 1245 1166 1091 981 842 798 - -

G3 1195 1118 1031 899 737 687 - -

G4 1160 1085 992 853 688 637 - -

Without 1590 1470 1354 1200 1023 968 909 -

G3 1490 1377 1247 1070 877 819 757 -

G4 1410 1301 1167 991 810 758 703 -

Without 1800 1658 1524 1358 1174 1119 1059 994

G3 1665 1533 1388 1202 1003 945 882 816

G4 1556 1430 1285 1102 914 860 802 741

Speeds Filter

External static pressure (Pa)

0 25 50 75 95 100 105 110

Without 790 729 670 610 ----

G3765704648587----

G4752696641582----

Without 990 929 859 748 611 - - -

G3 960 893 814 683 516 - - -

G4 940 874 792 659 491 - - -

Without 1280 1161 1050 912 758 711 - -

G3 1220 1098 977 826 663 614 - -

G4 1145 1053 936 787 637 594 - -

Without 1545 1403 1250 1072 899 851 800 -

G3 1430 1288 1137 959 786 736 685 -

G4 1340 1210 1069 900 735 688 639 -

Without 1760 1588 1401 1194 1007 956 905 852

G3 1595 1428 1251 1055 878 830 781 731

G4 1470 1320 1159 980 821 779 736 691
