Airwell VH 07 [17/32] Performance data in cooling mode 4 pipe system

17

Performance Data in Cooling Mode - 4-pipe system

Performance data based on :

- Air : 27 °C/19 °C (wet bulb), Chilled water : 7/12 °C. Units with G3 filter and 50 Pa external static pressure.

- Circular return/Circular discharge for sizes 03 to 10 and Rectangular return/Rectangular discharge for sizes 15 to 27.

VH sizes Speeds V1 V2 V3 V4 V5 V6

03

Air flow m³/h - 148 271 390 462 570

Total capacity W - 1030 1371 1527 1585 1649

Sensible capacity W - 719 1058 1298 1423 1595

10

Air flow m³/h 643 829 1027 1292 1486 -

Total capacity W 3581 4267 5045 5769 6409 -

Sensible capacity W 2707 3312 4016 4718 5294 -

15

Air flow m³/h 671 1285 2112 2617 3176 -

Total capacity W 5065 7924 10463 11582 12575 -

Sensible capacity W 3702 6170 8837 10240 11666 -

18

Air flow m³/h 671 1285 2112 2617 3176 -

Total capacity W 5276 8514 11567 12969 14251 -

Sensible capacity W 3843 6543 9546 11156 12814 -

Sensible capacity W 10230 12160 14715 17346 - -

27

Air flow m³/h 1938 2413 3103 3882 - -

Total capacity W 14678 17303 20662 23945 - -

Sensible capacity W 10675 12799 15679 18686 - -

Performance Data in Heating Mode - 4-pipe system

Performance data based on :

- Air : 20 °C, hot water : 70/60 °C.

- Units with G3 filter and 50 Pa external static pressure.

- Circular return/Circular discharge for sizes 03 to 10 and Rectangular return/Rectangular discharge for sizes 15 to 27.

Heating capacity W - 3249 3770 4373 5137 5984

07

Air flow m³/h 648 814 977 1137 1251 -

Heating capacity W 5620 6597 7479 8278 8815 -

10

Air flow m³/h 643 829 1027 1292 1486 -

Heating capacity W 7791 9103 10167 12062 13418 -

15

Air flow m³/h 671 1285 2112 2617 3176 -

Heating capacity W 8150 13468 19220 22218 25215 -

24

Air flow m³/h 1938 2413 3103 3882 - -

Heating capacity W 20157 23636 28176 32766 - -

27

Air flow m³/h 1938 2413 3103 3882 - -

Heating capacity W 20176 23639 28177 32786 - -
