Airwell VH 07 [16/32] Performance data in cooling mode 2 pipe system

16

Performance Data in Cooling Mode - 2-pipe system

Performance data based on :

-

Air : 27 °C/19 °C (wet bulb), Chilled water : 7/12 °C. Units with G3 filter and 50 Pa external static pressure.

- Circular return/Circular discharge for sizes 03 to 10 and Rectangular return/Rectangular discharge for sizes 15 to 27.

VH sizes Speeds V1 V2 V3 V4 V5 V6

03

Air flow m³/h - 148 271 390 462 570

Total capacity W - 1162 1646 1886 1980 2083

Sensible capacity W - 792 1218 1524 1686 1909

10

Air flow m³/h 643 829 1027 1292 1486 -

Total capacity W 4577 5560 6539 7615 8458 -

Sensible capacity W 3267 4028 4815 5727 6408 -

15

Air flow m³/h 671 1285 2112 2617 3176 -

Total capacity W 5351 8716 11927 13416 14819 -

Sensible capacity W 3855 6586 9614 11232 12896 -

18

Air flow m³/h 671 1285 2112 2617 3176 -

Total capacity W 5753 9949 14428 16685 18888 -

Sensible capacity W 4041 7186 10844 12847 14923 -

Sensible capacity W 10670 12793 15642 18623 - -

27

Air flow m³/h 1938 2413 3103 3882 - -

Total capacity W 16107 19399 23798 28364 - -

Sensible capacity W 11331 13780 17147 20761 - -

Performance Data in Heating Mode - 2-pipe system

Performance data based on :

- Air : 20 °C, entering water temperature : 50 °C, water flow is the same as that in cooling mode.

- Units with G3 filter and 50 Pa external static pressure.

- Circular return/Circular discharge for sizes 03 to 10 and Rectangular return/Rectangular discharge for sizes 15 to 27.

Heating capacity W - 2485 2911 3372 3964 4564

07

Air flow m³/h 648 814 977 1137 1251 -

Heating capacity W 5160 6149 7058 7861 8360 -

10

Air flow m³/h 643 829 1027 1292 1486 -

Heating capacity W 5627 7001 8396 10251 11658 -

15

Air flow m³/h 671 1285 2112 2617 3176 -

Heating capacity W 5886 10114 14870 17384 19913 -

24

Air flow m³/h 1938 2413 3103 3882 - -

Heating capacity W 17813 21616 26823 32282 - -

27

Air flow m³/h 1938 2413 3103 3882 - -

Heating capacity W 18276 22286 27883 33870 - -
