18
Eurovent Performance Data
Sizes
Fan
speed
Air flow
(m
3
/h)
External
static
pressure
(Pa)
Cooling Heating Sound levels Lw
Total
capacity (W)
Sensible
capacity (W)
WPD
(kPa)
Heating cap.
(W)
WPD
(kPa)
Return +
radiated (dBA)
Discharge
(dBA)
VH 03
LS 141 15 1087 736 3.1 1190 2.5 41.3 39.5
MS 271 50 1646 1218 6.6 2082 5.2 56.2 54.9
HS 395 110 1888 1527 8.4 2729 6.7 65.1 64.4
VH 05
LS 270 35 1953 1386 5.2 2354 4.1 48.2 47.4
MS 340 50 2283 1660 6.5 2911 5.0 53.2 52.0
HS 398 70 2419 1785 7.2 3184 5.7 56.4 55.5
VH 07
LS 703 30 4560 3266 27.4 5373 21.5 53.8 52.6
MS 977 50 5503 4148 39.2 7058 31.1 60.3 58.6
HS 1125 70 5814 4474 43.5 7628 34.5 63.0 61.5
VH 10
LS 705 25 4823 3469 13.1 6020 11.6 51.2 49.1
MS 1027 50 6531 4809 22.9 8443 20.6 59.5 57.8
HS 1255 75 7801 5722 31.8 10179 28.8 63.7 62.3
VH 15
LS 960 15 7084 5218 7.9 8007 6.3 52.2 52.0
MS 2112 50 11926 9614 19.8 14870 16.0 65.5 64.4
HS 2830 90 13987 11892 26.1 18365 21.1 71.8 70.9
VH 18
LS 960 15 7856 5585 6.8 8730 5.4 52.2 52.0
MS 2112 50 14428 10844 19.6 17054 15.7 65.5 64.4
HS 2830 90 17559 13658 27.6 21619 22.3 71.8 70.9
VH 21
LS 960 15 8294 5777 8.5 9014 7.0 52.2 52.0
MS 2112 50 16129 11691 28.7 18111 23.7 65.5 64.4
HS 2830 90 20184 14942 43.5 23106 36.0 71.8 70.9
VH 24
LS 2040 35 15173 11105 13.3 18590 10.5 65.0 63.5
MS 2413 50 17243 12793 16.6 21616 13.2 69.1 66.9
HS 2925 75 19724 14886 21.1 25312 16.7 72.5 71.5
VH 27
LS 2040 35 16781 11830 13.6 19066 11.4 65.0 63.5
MS 2413 50 19399 13780 17.6 22286 14.7 69.1 66.9
HS 2925 75 22639 16244 23.0 26371 19.3 72.5 71.5
Sizes
Fan
speed
Air flow
(m
3
/h)
External
static
pressure
(Pa)
Cooling Heating Sound levels Lw
Total
capacity (W)
Sensible
capacity (W)
WPD
(kPa)
Heating cap.
(W)
WPD
(kPa)
Return +
radiated (dBA)
Discharge
(dBA)
VH 03
LS 141 15 973 674 2.3 1357 1.9 41.3 39.5
MS 271 50 1371 1058 4.3 2257 4.9 56.2 54.9
HS 395 110 1528 1300 5.2 2911 7.9 65.1 64.4
VH 05
LS 270 35 1958 1409 4.6 3084 17.7 48.2 47.4
MS 340 50 2303 1724 5.9 3768 23.6 53.2 52.0
HS 398 70 2444 1865 6.5 4127 27.7 56.4 55.5
VH 07
LS 703 25 4178 2992 19.6 5892 9.5 53.8 52.6
MS 977 50 5017 3746 26.9 7472 13.6 60.3 58.6
HS 1125 70 5296 4024 29.7 8053 15.5 63.0 61.5
VH 10
LS 705 25 3719 2832 5.9 8304 25.9 51.2 49.1
MS 1027 50 5045 4016 10.4 10132 36.9 59.5 57.8
HS 1255 75 6063 4795 14.5 11897 48.6 63.7 62.3
VH 15
LS 960 15 6562 4944 5.8 10800 38.7 52.2 52.0
MS 2112 50 10463 8837 13.3 19191 108.7 65.5 64.4
HS 2830 90 11992 10808 16.9 23378 155.8 71.8 70.9
VH 18
LS 960 15 6953 5193 6.9 10887 23.8 52.2 52.0
MS 2112 50 11567 9546 17.1 19189 66.3 65.5 64.4
HS 2830 90 13495 11812 22.6 23367 95.0 71.8 70.9
VH 21
LS 960 15 7934 5625 11.1 10887 23.8 52.2 52.0
MS 2112 50 14761 10973 34.9 19189 66.3 65.5 64.4
HS 2830 90 18098 13856 50.9 23367 95.0 71.8 70.9
VH 24
LS 2040 35 14051 10629 15.3 20884 74.0 65.0 63.5
MS 2413 50 15789 12160 18.8 23596 92.7 69.1 66.9
HS 2925 75 17809 14040 23.3 26948 118.2 72.5 71.5
VH 27
LS 2040 35 15220 11109 13.5 20857 46.2 65.0 63.5
MS 2413 50 17303 12799 17.0 23585 58.0 69.1 66.9
HS 2925 75 19793 14913 21.5 26918 74.6 72.5 71.5
2-pipe system
4-pipe system
Performance data based on :
- Cooling : Air : 27 °C/19 °C (wet bulb) - Chilled water : 7/12 °C.
- Heating : Air : 20 °C, entering water temperature 50 °C, water flow identical to chilled water flow.
- Units with G3 filter.
Circular return/Circular discharge for sizes 03 to 10 and Rectangular return/Rectangular discharge for sizes 15 to 27.
- According to Eurovent 6/9, Eurovent 6/10, Eurovent 8/12.
Performance data based on :
- Cooling : Air : 27 °C/19 °C (wet bulb) - Chilled water : 7/12 °C.
-
Heating : Air : 20 °C - Hot water : 70/60 °C.
- Units with G3 filter.
Circular return/Circular discharge for sizes 03 to 10 and Rectangular return/Rectangular discharge for sizes 15 to 27.
- According to Eurovent 6/9, Eurovent 6/10, Eurovent 8/12.
