Air Flow Data (continued)

VH 15, 18 & 21 - Rectangular return / Rectangular discharge - Air flow (m

/h)

VH 24 & 27 - Rectangular return / Rectangular discharge - Air flow (m

/h)

Speeds Filter

Pression disponible (Pa)

0 25 50 75 100 125 150 180 190 200

Without 1150 949 739 540 ------

G3 1070 882 671 480 ------

G4 1040 859 665 473 ------

Without 1685 1530 1370 1207 1040 870 700 - - -

G3 1559 1431 1285 1138 994 847 681 - - -

G4 1521 1381 1242 1104 965 824 679 - - -

Without 2500 2378 2243 2093 1912 1707 1490 1100 - -

G3 2370 2249 2112 1958 1789 1598 1371 1000 - -

G4 2280 2151 1996 1848 1683 1487 1257 876 - -

Without 3130 2965 2786 2603 2404 2175 1915 1560 1410 -

G3 2905 2770 2617 2443 2250 2039 1801 1450 1307 -

G4 2751 2587 2426 2248 2049 1831 1593 1260 1130 -

Without 3830 3630 3403 3177 2933 2662 2373 1996 1854 1699

G3 3545 3369 3176 2967 2739 2490 2220 1850 1710 1560

G4 3240 3048 2847 2634 2408 2170 1918 1588 1468 1341

Speeds Filter

Pression disponible (Pa)

0 25 50 75 100 150 175 200 210 220

Without 2390 2229 2062 1878 1681 1260 1010 - - -

G3 2230 2093 1938 1765 1580 1178 940 - - -

G4 2149 2025 1862 1687 1510 1137 900 - - -

Without 2860 2720 2553 2373 2179 1732 1472 1184 - -

G3 2720 2572 2413 2235 2046 1640 1400 1138 - -

G4 2580 2416 2264 2107 1935 1524 1285 1032 - -

Without 3650 3489 3320 3133 2928 2472 2199 1861 1700 -

G3 3450 3290 3103 2914 2700 2223 1950 1610 1470 -

G4 3202 3055 2890 2708 2514 2088 1835 1515 1357 -

Without 4650 4454 4229 4001 3750 3179 2863 2494 2326 2149

G3 4270 4099 3882 3667 3432 2890 2578 2206 2044 1892

G4 3861 3679 3487 3277 3049 2551 2276 1959 1813 1650
