Airwell VLC 604 [11/24] Electrical data vlc std units continued

Page 11

Electrical Data - VLC STD Units (continued)

Fans - 400 V / 3 Ph / 50 Hz (continued)

VLC ELN models 524 604 704 804 904 1004 1104 1204

Number of fans 2 3 3 3 4 4 4 4

Nominal power per fan kW 1.25 1.25 1.25 1.25 1.25 1.25 1.25 1.25

Max. running current per fan A 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3

Total fan power

kW 2.5 3.75 3.8 3.8 5.0 5.0 5.0 5.0

Total max. fan current

A 4.6 6.9 6.9 6.9 9.2 9.2 9.2 9.2

Units - 400 V / 3 Ph / 50 Hz

VLC BLN models 524 604 704 804 904 1004 1104 1204

Nominal power input kW 50.0 56.0 65.4 69.6 84.4 97.2 103.6 110.0

Maximum power input kW 60.0 69.6 80.8 96.4 105.2 112.0 130.0 148.0

Nominal current input A 88.0 100.0 112.0 120.0 142.0 160.0 172.0 184.0

Maximum current input A 148.0 156.0 186.0 172.0 193.0 210.0 239.0 268.0

Start-up current

A 271 280 350 357 378 434 486 515

VLC LN models 524 604 704 804 904 1004 1104 1204

Nominal power input kW 48.5 53.8 63.2 67.4 81.4 94.2 100.6 107.0

Maximum power input kW 58.5 67.4 78.6 94.2 102.2 109.0 127.0 145.0

Nominal current input A 84.6 94.9 106.9 114.9 135.2 153.2 165.2 177.2

Maximum current input A 144.6 150.9 180.9 166.9 186.2 203.2 232.2 261.2

Start-up current

A 268 275 345 352 371 427 479 508

VLC ELN models 524 604 704 804 904 1004 1104 1204

Nominal power input kW 48.5 53.8 63.2 67.4 81.4 94.2 100.6 107.0

Maximum power input kW 58.5 67.4 78.6 94.2 102.2 109.0 127.0 145.0

Nominal current input A 84.6 94.9 106.9 114.9 135.2 153.2 165.2 177.2

Maximum current input A 144.6 150.9 180.9 166.9 186.2 203.2 232.2 261.2

Start-up current

A 267.6 275 345 352 371 427 479 508
