Airwell VLC 604 [6/24] Physical data vlc std hse sif bln version
![Airwell VLC 604 [6/24] Physical data vlc std hse sif bln version](/views2/1408279/page6/bg6.png)
Page 6
Physical Data - VLC STD/HSE/SIF - BLN Version
(1) Data based on 7 °C evaporating temperature and 35 °C ambient air temperature.
(2) Compressors only.
(3) Sound levels are at fully loaded conditions. Sound power level values refer to ISO standard 3744 and Eurovent 8/1.
(4) Sound pressure levels refer to ISO standard 3744, parallelepiped shape.
(*) High efficiency units (HSE) with inverter fans.
(**) SIF units with high static pressure fans.
VLC STD/HSE/SIF-BLN models 524 604 704 804 904 1004 1104 1204
Nominal cooling capacity (1) kW 154.0 174.0 199.0 224.0 258.0 283.0 315.0 347.0
Input power (2) kW 47.5 52.5 63.0 69.0 79.0 83.0 98.0 112.0
Number of refrigerant circuits 2 2 2 2 2 2 2 2
Total capacity steps %
25-50
75-100
28-57
78-100
20-50
70-100
25-50
75-100
28-50
78-100
25-50
75-100
23-50
73-100
25-50
75-100
COMPRESSORS
Number 4 4 4 4 4 4 4 4
Type
SCROLL
Oil type POE
N° of loading stages 0/100 0/100 0/100 0/100 0/100 0/100 0/100 0/100
AIR COOLED CONDENSERS
Number of coils 2 2 2 2 2 2 2 2
Total coil face area per coil
m
2
3.5 3.5 4.8 4.8 4.8 4.8 4.8 4.8
FANS
Number of fans 2 3 3 3 4 4 4 4
Nominal speed rpm 900 900 900 900 900 900 900 900
Total airflow
m
3
/h 46300 63000 68300 68300 85000 80000 75500 75500
Total input power
kW 3.8 5.7 5.7 5.7 7.6 7.6 7.6 7.6
Total input power
(*) kW 2.6 4.0 4.0 4.0 5.3 5.3 5.3 5.3
External static pressure Pa 0 or 120 Pa (**)
REFRIGERANT CONNECTION
In inch 7/8" 7/8" 7/8" 7/8" 1 1/8" 1 1/8" 1 1/8" 1 1/8"
Out inch 1 5/8" 1 5/8" 1 5/8" 1 5/8" 2 1/8" 2 1/8" 2 1/8" 2 1/8"
WEIGHT
Shipping weight kg 1080 1300 1490 1615 1700 1825 1910 1920
ADDITIONAL WEIGHT
HSE version kg 30 30 30 30 40 40 40 40
SIF version kg 10 10 10 10 15 15 15 15
SOUND LEVELS
Sound power level (3) dB(A) 92 93 93 93 94 94 95 95
Sound pressure level - (10 m) (4) dB(A) 60 61 61 61 62 62 63 63
DIMENSIONS
Length
mm 3300 3300 4300 4300 4300 4300 4300 4300
Width mm 1100 1100 1100 1100 1100 1100 1100 1100
Height mm 2300 2300 2300 2300 2300 2300 2300 2300
