Single unit applications
Multi units applications
LOUVRED A & C
SOLID B & D
SOLID A & B
SOLID C & D
SOLID A & C
LOUVRED B & D
LOUVRED A & B
SOLID C & D
LOUVRED A & D
SOLID B & C
A1 A2 A3 A1 A2 A3 A1 A2 A3 A1 A2 A3 A1 A2 A3
ARRANGEMENT 1 1000 1000 1000 1000 800 800 1000 800 800 1000
ARRANGEMENT 2 1000 1500 1000 1000 2000 1000 800 2000 800 1000 1500 800 800 1500 1000
Note : No more than one wall can be higher than the unit.
The area enclosed by the wall must be kept clear of all obstructions that would impede air flow to the unit.
Dimensions in mm.
Space Requirements
1500 mm
1500 mm
1500 mm
1000 mm
3000 mm
1.0 m
1.5 m
2.0 m
A1 A2
1.5 m
1.0 m
A2 A3A1
A
VIEW A
WALL A
WALL D WALL B
WALL CWALL C
WALL A
WALL D WALL B
ARRANGEMENT 1 ARRANGEMENT 2
