![Airwell VLC 604 [15/24] Cooling capacities vlc std hse sif bln version](/views2/1408279/page15/bgf.png)
Page 15
Cooling Capacities - VLC STD/HSE/SIF - BLN Version
Note : Power input data are given for compressors only.
Models
Evap.
Temp.
(°C)
Condensing Air Temperature (°C)
25 30 32 35 40 44 46
Cool.
cap.
(kW)
Input
Power
(kW)
Cool.
cap.
(kW)
Input
Power
(kW)
Cool.
cap.
(kW)
Input
Power
(kW)
Cool.
cap.
(kW)
Input
Power
(kW)
Cool.
cap.
(kW)
Input
Power
(kW)
Cool.
cap.
(kW)
Input
Power
(kW)
Cool.
cap.
(kW)
Input
Power
(kW)
524
BLN
2 151.7 37.6 144.4 41.2 141.3 42.8 136.6 45.0 127.0 49.9 121.0 53.1 115.1 56.2
3 155.5 38.0 148.0 41.7 144.9 43.2 140.0 45.5 130.2 50.4 124.1 53.6 118.0 56.8
4 159.4 38.5 151.7 42.2 148.4 43.7 143.6 45.9 133.5 50.9 127.2 54.1 121.0 57.3
5 163.2 39.0 155.3 42.6 152.0 44.2 147.0 46.5 136.5 51.4 130.2 54.6 123.9 57.9
7 171.0 39.9 162.7 43.7 159.3 45.2 154.0 47.5 143.1 52.5 136.4 55.8 129.7 59.1
10 182.6 41.5 173.9 45.2 170.2 46.8 164.4 49.1 152.9 54.2 145.7 57.5 138.6 60.8
604
BLN
2 171.4 41.6 163.1 45.6 159.6 47.3 154.4 49.7 143.5 55.2 136.8 58.7 130.1 62.2
3 175.7 42.1 167.2 46.1 163.7 47.8 158.2 50.3 147.1 55.7 140.2 59.2 133.4 62.7
4 180.1 42.6 171.4 46.6 167.7 48.3 162.2 50.8 150.8 56.3 143.8 59.8 136.7 63.3
5 184.4 43.1 175.5 47.1 171.8 48.9 166.1 51.4 154.2 56.8 147.1 60.4 139.9 64.0
7 193.2 44.2 183.8 48.3 180.0 50.0 174.0 52.5 161.7 58.1 154.1 61.7 146.5 65.3
10 206.4 45.9 196.5 49.9 192.3 51.7 185.8 54.3 172.8 59.9 164.7 63.5 156.6 67.2
704
BLN
2 196.1 49.9 186.5 54.7 182.6 56.7 176.5 59.7 164.1 66.2 156.4 70.4 148.8 74.6
3 201.0 50.5 191.3 55.3 187.3 57.3 181.0 60.3 168.3 66.8 160.4 71.1 152.5 75.3
4 206.0 51.1 196.0 56.0 191.8 58.0 185.6 60.9 172.5 67.5 164.4 71.8 156.4 76.0
5 210.9 51.7 200.7 56.6 196.4 58.6 190.0 61.7 176.4 68.2 168.2 72.5 160.1 76.8
7 221.0 53.0 210.2 57.9 205.8 60.0 199.0 63.0 184.9 69.7 176.3 74.0 167.6 78.3
10 236.0 55.0 224.7 59.9 219.9 62.0 212.5 65.2 197.6 71.9 188.3 76.2 179.0 80.6
804
BLN
2 220.7 54.6 210.0 59.9 205.5 62.1 198.7 65.4 184.7 72.5 176.1 77.1 167.5 81.7
3 226.2 55.3 215.3 60.6 210.8 62.8 203.7 66.1 189.4 73.2 180.6 77.8 171.7 82.5
4 231.9 55.9 220.6 61.3 215.8 63.5 208.9 66.7 194.2 73.9 185.1 78.6 176.0 83.2
5 237.4 56.7 225.9 61.9 221.1 64.2 213.8 67.5 198.6 74.7 189.4 79.4 180.2 84.1
7 248.7 58.0 236.6 63.5 231.7 65.7 224.0 69.0 208.2 76.3 198.4 81.1 188.6 85.8
10 265.6 60.3 252.9 65.6 247.6 67.9 239.2 71.4 222.5 78.7 212.0 83.5 201.5 88.3
904
BLN
2 254.2 62.5 241.8 68.6 236.7 71.1 228.9 74.8 212.7 83.0 202.8 88.3 192.9 93.5
3 260.6 63.3 248.0 69.3 242.8 71.9 234.6 75.7 218.1 83.8 208.0 89.1 197.8 94.4
4 267.1 64.0 254.1 70.2 248.6 72.7 240.6 76.4 223.6 84.7 213.2 90.0 202.7 95.3
5 273.4 64.9 260.2 70.9 254.7 73.5 246.3 77.3 228.7 85.5 218.1 90.9 207.5 96.3
7 286.5 66.4 272.5 72.7 266.9 75.2 258.0 79.0 239.8 87.4 228.5 92.8 217.3 98.2
10 306.0 69.0 291.3 75.2 285.1 77.8 275.5 81.7 256.2 90.1 244.2 95.6 232.1 101.1
1004
BLN
2 278.8 65.7 265.3 72.1 259.6 74.7 251.1 78.6 233.3 87.2 222.4 92.8 211.6 98.3
3 285.8 66.5 272.0 72.8 266.3 75.5 257.3 79.5 239.3 88.1 228.1 93.6 216.9 99.2
4 292.9 67.3 278.7 73.7 272.7 76.4 263.9 80.3 245.3 88.9 233.8 94.5 222.3 100.1
5 299.9 68.1 285.4 74.5 279.4 77.2 270.2 81.2 250.9 89.8 239.2 95.5 227.6 101.1
7 314.2 69.8 298.9 76.3 292.7 79.0 283.0 83.0 263.0 91.8 250.7 97.5 238.3 103.2
10 335.6 72.5 319.5 79.0 312.8 81.7 302.2 85.9 281.0 94.7 267.8 100.5 254.6 106.2
1104
BLN
2 310.3 77.6 295.3 85.1 289.0 88.2 279.4 92.8 259.7 103.0 247.6 109.5 235.5 116.0
3 318.1 78.5 302.8 86.0 296.4 89.1 286.4 93.9 266.3 104.0 253.9 110.5 241.5 117.1
4 326.1 79.4 310.2 87.0 303.5 90.2 293.7 94.8 273.0 105.0 260.3 111.6 247.5 118.2
5 333.8 80.5 317.7 88.0 310.9 91.2 300.7 95.9 279.2 106.1 266.3 112.7 253.4 119.4
7 349.8 82.4 332.8 90.1 325.8 93.3 315.0 98.0 292.7 108.4 279.0 115.1 265.3 121.9
10 373.6 85.6 355.7 93.2 348.1 96.5 336.3 101.4 312.8 111.8 298.1 118.6 283.4 125.4
1204
BLN
2 341.9 88.6 325.3 97.2 318.3 100.8 307.8 106.1 286.1 117.7 272.8 125.2 259.4 132.6
3 350.4 89.7 333.5 98.3 326.5 101.9 315.5 107.3 293.4 118.8 279.7 126.3 266.0 133.9
4 359.2 90.8 341.7 99.5 334.4 103.1 323.6 108.3 300.8 120.0 286.7 127.6 272.6 135.1
5 367.8 92.0 350.0 100.5 342.5 104.2 331.3 109.6 307.6 121.2 293.3 128.8 279.1 136.5
7 385.3 94.2 366.6 103.0 358.9 106.6 347.0 112.0 322.5 123.9 307.3 131.6 292.2 139.3
10 411.5 97.8 391.8 106.6 383.5 110.3 370.5 115.9 344.6 127.7 328.4 135.5 312.2 143.4
