Electrical Data - VLC HSE/SIF/HT Units
Compressors @ 400 V / 3 Ph / 50 Hz
Models
Power input
at nominal
conditions per
compressor
(kW)
Current at
nominal
conditions per
compressor
(A)
Power input
at max.
conditions per
compressor
(kW)
Current
at max.
conditions per
compressor
FLA (A)
Start up
current LRA
(A)
Power factor
at nominal
conditions
Unit fuse
size (A)
Cable
section
(mm
2
)
524
Circuit 1
11.5 20 14.0 35.0 158 0.83
200 3 x 95
11.5 20 14.0 35.0 158 0.83
Circuit 2
11.5 20 14.0 35.0 158 0.83
11.5 20 14.0 35.0 158 0.83
604
Circuit 1
12.5 22 15.9 36.0 160 0.82
200 3 x 95
12.5 22 15.9 36.0 160 0.82
Circuit 2
12.5 22 15.9 36.0 160 0.82
12.5 22 15.9 36.0 160 0.82
704
Circuit 1
12.5 22 15.9 36.0 160 0.82
250 3 x 120
17.2 28 21.5 51.0 215 0.89
Circuit 2
12.5 22 15.9 36.0 160 0.82
17.2 28 21.5 51.0 215 0.89
804
Circuit 1
15.9 27 22.6 40.0 225 0.85
250 3 x 120
15.9 27 22.6 40.0 225 0.85
Circuit 2
15.9 27 22.6 40.0 225 0.85
15.9 27 22.6 40.0 225 0.85
904
Circuit 1
15.9 27 22.6 40.0 225 0.85
250 3 x 120
22.3 36 26.0 48.5 272 0.89
Circuit 2
15.9 27 22.6 40.0 225 0.85
22.3 36 26.0 48.5 272 0.89
1004
Circuit 1
22.3 36 26.0 48.5 272 0.89
250 3 x 120
22.3 36 26.0 48.5 272 0.89
Circuit 2
22.3 36 26.0 48.5 272 0.89
22.3 36 26.0 48.5 272 0.89
1104
Circuit 1
22.3 36 26.0 48.5 272 0.89
315 3 x 185
22.3 36 26.0 48.5 272 0.89
Circuit 2
25.5 42 35.0 63.0 310 0.88
25.5 42 35.0 63.0 310 0.88
1204
Circuit 1
25.5 42 35.0 63.0 310 0.88
315 3 x 185
25.5 42 35.0 63.0 310 0.88
Circuit 2
25.5 42 35.0 63.0 310 0.88
25.5 42 35.0 63.0 310 0.88
Fans - 400 V / 3 Ph / 50 Hz
VLC BLN models 524 604 704 804 904 1004 1104 1204
Number of fans 2 3 3 3 4 4 4 4
Nominal power per fan kW 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6
Max. running current per fan A 4.1 4.1 4.1 4.1 4.1 4.1 4.1 4.1
Total fan power
kW 5.2 7.8 7.8 7.8 10.4 10.4 10.4 10.4
Total max. fan current
A 8.2 12.3 12.3 12.3 16.4 16.4 16.4 16.4
VLC LN models 524 604 704 804 904 1004 1104 1204
Number of fans 2 3 3 3 4 4 4 4
Nominal power per fan kW 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6
Max. running current per fan A 4.1 4.1 4.1 4.1 4.1 4.1 4.1 4.1
Total fan power
kW 5.2 7.8 7.8 7.8 10.4 10.4 10.4 10.4
Total max. fan current
A 8.2 12.3 12.3 12.3 16.4 16.4 16.4 16.4
Note : The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider : the rating, the maximum working
temperature in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
