Airwell Rooftech 100 [10/62] Electrical specifications
![Airwell Rooftech 100 [10/62] Electrical specifications](/views2/1408342/page10/bga.png)
8
INSTALLATION
ELECTRICAL SPECIFICATIONS
IMPORTANT
** for all other capacities, please consult us.
A main fuse must mandatorily be provided on the power supply.
Fuses not supplied
Cables not supplied
The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work or
constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or a
collapse with dangerous consequences for personnel and property. In such an event, the warranty
shall be null and avoid.
The unit supporting base shall be supplied as indicated in the manual. There could be a risk of
personal injury or damage to property in the event of the unit being incorrectly supported.
The building structure must be capable of carrying the weight of the unit during operation.
The place of installation must not be subject to flooding.
The ROOFTECH should be installed on a flat, clean surface without any obstacles. The surface area
must be sufficient to spread the weight of the unit over the building structure.
Ensure that the recommended free clearances around the unit are maintained to avoid any risk of
malfunctions.
The installer is responsible for providing the weaterproof seal between the building and the ROOFTECH.
The installer must be fully versed in the practice of roof mounted equipments and must comply with
the recommendations and rules detailed in the Technical Directives.
In order to avoid risk of condensation and energy losses, all outdoor ducting and piping must be
insulated.
The unit’s tightness must not be deteriorated by power supply connections.
UNIT WITHOUT HEATING
UNIT WITH HEATING TYPE CH1
PLACE OF INSTALLATION AND REQUIREMENTS
UNIT WITH HEATING TYPE CH2
Models
100 120 140 160
PE GE PE GE PE GE PE GE
Power supply 3+N /400 /50Hz
Maximum current A 123 136 127 140 139 152 167 180
Total starting current A 209.6 223 231.6 245 228.6 242 289.6 303
Fuse rating aM A 160 160 160 160 160 160 200 200
Models
100 120 140 160
PE GE PE GE PE GE PE GE
Power supply 3 /400 /50Hz
Capacities **
KW 63
Maximum current A 233 246 237 250 249 262 277 290
Total starting current A 319.6 333 341.6 355 338.6 352 399.6 413
Fuse rating aM A 250 250 250 250 250 315 315 315
Models
100 120 140 160
PE GE PE GE PE GE PE GE
Power supply 3 /400 /50Hz
Capacities **
KW 105
Maximum current A 306 319 310 323 322 335 350 363
Total starting current A 392.6 406 414.6 428 411.6 425 472.6 486
Fuse rating aM A 315 315 315 400 400 400 400 400
