Airwell AQCL 120 [9/20] Electrical data
![Airwell AQCL 120 [9/20] Electrical data](/views2/1408566/page9/bg9.png)
Page 9
Electrical Data
AQCL sizes Fuse aM type - (A) Full load current (max.) 400V - (A) Starting current (max.) - (A)
25 32 25 80
30 32 27 82
35 40 31 122
40 50 44 140
50 50 47 186
60 63 53 232
70 80 68.8 230
80 80 71 233
100 125 102 322
120 175 110 330
130 175 120 340
AQCL sizes Fuse aM type - (A) Full load current (max.) 400V - (A) Starting current (max.) - (A)
25 32 27 82
30 32 29 92
35 40 33 124
40 63 47 142
50 63 51 188
60 63 56 236
70 80 71.8 233
80 80 74 236
100 125 105 325
120 175 113 333
130 175 123 343
AQCL SIZES 25 30 35 40 50 60 70 80 100 120 130
Nominal power consumption kW 4.3+4.3 5.0+5.0 6.1+6.1 7.9+6.4 11.2+6.4 13.8+7.6 13.8+11.2 13.8+13.8 12.3+20.2 16.5+20.2 20.2+20.2
Maximum power consumption kW 6+6 7+7 8+8 10+8 15+8 18+10 18+15 18+18 17.3+29 23.8+29 29+29
Nominal current A 8.1+8.1 8.8+8.8 11.2+11.2 14.3+12.2 19.3+12.2 23.1+14.3 23.1+19.3 23.1+23.1 22.3+35.1 28.6+35.1 35.1+35.1
Maximum current A 10+10 11.4+11.4 13.3+13.3 18+14.6 25.6+14.6 27.8+18 27.8+25.6 27.8+27.8 29.2+47 38.5+47 47+47
Crankcase heater W 70+70 70+70 70+70 70+70 70+70 70+70 70+70 70+70 75+130 130+130 130+130
AQCL SIZES 25 30 35 40 50 60 70 80 100 120 130
Supply voltage (V / Ph / Hz) 400 / 3 /50
Nominal power input kW 3.0 3.0 3.0 4.0 5.5 5.5 7.5 7.5 7.5 7.5 7.5
Nominal current input A 6.3 6.3 6.3 8.1 11.0 11.0 14.7 14.7 14.7 14.7 14.7
AQCL SIZES 25 30 35 40 50 60 70 80 100 120 130
Supply voltage (V / Ph / Hz) 400 / 3 /50
Nominal power input kW 4.0 4.0 4.0 5.5 7.5 7.5 11 11 11 11 11
Nominal current input A 8.1 8.1 8.1 11.0 14.7 14.7 21 21 21 21 21
AQCL SIZES 25 30 35 40 50 60 70 80 100 120 130
Supply voltage (V / Ph / Hz) 400 / 3 /50
Nominal power input kW 0.55 0.55 0.55 0.75 0.75 1.1 1.1 1.1 1.85 1.85 1.85
Nominal current input A 1.7 1.7 1.7 2.1 2.1 3.1 3.1 3.1 4.6 4.6 4.6
AQCL SIZES 25 30 35 40 50 60 70 80 100 120 130
Supply voltage (V / Ph / Hz) 230 / 1 /50
Maximum power input W 35 35 35 35 35 35 35 35 35 35 35
Unit with standard fan motors
Unit with high static fan motors (optional)
Compressors
Standard fan motors
High static fan motors (optional)
Standard pumps
Evaporator heating resistance
