ULTIMA COMPACT Chillers
Chillers
6
Installation & Maintenance : 903-129 IM E 10/04/C
General Description
AIR COOLED LIQUID CHILLER
UCC Ultima Compact Chiller - Cooling Only
30 - 450
Model Size (Expressed as Nominal Cooling in kW)
SQ- Single Circuit - Quiet Chiller (Models 30-80 (Except 75) Only)
SSQ- Single Circuit - Super Quiet Chiller (Models 30-80 (Except 75) Only)
D- Double Circuit - Standard Chiller
DQ- Double Circuit - Quiet Chiller
DSQ- Double Circuit - Super Quiet Chiller
2-16
Number of Fans
/1 or /2
Single or Double Row of Fans
UNIT IDENTIFICATION
Example UCC250DQ-8/2
The Airedale range of Ultima Compact air cooled liquid chillers covers the nominal
capacity range 30kW to 450kW in 23 model sizes. The range is available with many
optional variations including Quiet and Super Quiet sound level variants.
INTRODUCTION
Attention has been placed on maximising the unit’s performance while keeping the sound
and vibration levels and footprint to an absolute minimum.
Airedale certify that the equipment detailed in this manual conforms with the following
EC Directives:
Electromagnetic Compatibility Directive (EMC)
89/336/EEC
Low Voltage Directive (LVD)
73/23/EEC
Machinery Directive (MD)
89/392/EEC in the version 98/37/EC
Pressure Equipment Directive (PED)
97/23/EC
CE DIRECTIVE
To comply with these directives appropriate national & harmonised standards have been
applied. These are listed on the Declaration of Conformity, supplied with each product.
REFRIGERANTS
The range has been designed and optimised for operation with the ozone benign
R407C refrigerant.
