Chillers
ULTIMA COMPACT
Technical Manual : Part No 903-129 TM E 10/04/C
Chillers
7
FEATURES
UCC30, UCC40,
UCC50, UCC60, UCC70
& UCC80
UCC75, UCC100,
UCC125 &
UCC150
UCC110,
UCC130, UCC160
& UCC180
UCC200, UCC225
& UCC250
UCC275, UCC300,
UCC330, UCC360,
UCC400 & UCC450
Construction
4 x eye bolts to BS4278 or Integrated lugs/Mounting feet Integrated lugs Lifting Eye Bolts Lifting Eye Bolts Lifting Eye Bolts Lifting Eye Bolts
Acoustically lined compressor enclosure SSQ/DSQ Models DSQ Models DSQ Models DSQ Models DSQ Models
Refrigeration
Full Operating Charge of R407C Std Std Std Std Std
Number of Independent Refrigeration Circuits 1 or 2 2 2 2 2
Scroll Compressor Arrangement
1 x Tandem Set
or 2 x Single
2 x Tandem Sets 2 x Tandem Sets 2 x Tandem Sets
2 x Tandem Sets
(UCC275-300)
2 x Trio Sets
(UCC330-450)
Plate Evaporator Std Std Std Std Std
Enhanced Refrigeration Condenser Coils SSQ/DSQ Models DSQ Models DSQ Models DSQ Models DSQ Models
Sickle Bladed Fans - Long Bellmouth Long Bellmouth Long Bellmouth Long Bellmouth
Low speed condenser fan SQ/DQ Models DQ Models DQ Models DQ Models DQ Models
Extra Low speed condenser fan SSQ/DSQ Models DSQ Models DSQ Models DSQ Models DSQ Models
Thermostatic Expansion valve & Liquid line solenoid valve Std Std Std Std -
Electronic Expansion Valve
Opt (SQ/DQ Models)
Opt (SSQ/DSQ Models)
DQ/DSQ Models
Opt (D Models)
DQ/DSQ Models
Opt (D Models)
DQ/DSQ Models
Opt (D Models)
Std
Water Inlet/Outlet Threaded BSP female Flanged PN16 Flanged PN16 Flanged PN16 Flanged PN16
Liquid line sight glass Std Std Std Std Std
Liquid and Discharge line ball valve Opt Std Std Std Std
Large capacity filter drier Fixed Cores
Replaceable Cores Replaceable Cores Replaceable Cores
Replaceable Cores
Manual reset HP/LP Switch (LP via microprocessor) Std Std Std Std Std
Suction and liquid pressure transducers Std Std Std Std Std
Compressor minimum differential pressure protection Std Std Std Std Std
Pressure relief valve, integral rupture disc & gauge Std Std Std Std Std
Electrical
AireTronix Microprocessor Controller Std Std Std Std Std
Modulating Head Pressure Control Std Std Std Std Std
Emergency stop - Std Std Std Std
Individual door isolated mains power compartments for
each refrigeration CCT, fans & pump option
- - Std Std Std
Dedicated bus-bar chamber for incoming 3-phase & earth
mains power supply (no neutral required)
- - Std Std Std
Evaporator Pad Heater Std Std Std Std Std
Trace Heating to Internal Pipework Std Std Std Std Std
Connections for External Trace Heating Std Std Std Std Std
Phase Rotation Protection Opt Opt Opt Std Opt
Power Factor Correction - Opt Opt Opt Opt
