ULTIMA COMPACT Chillers
Chillers
28
Installation & Maintenance : 903-129 IM E 10/04/C
Installation Data
ELECTRICAL DATA
UCC300D-8/2 UCC330D-10/2 UCC360D-10/2 UCC400D-12/2 UCC450D-12/2
Unit Data
Nominal Run Amps (1) A 173 198 216 240 260
Maximum Start Amps (2) A 454 435 453 520 540
Permanent Supply VAC 230 V 1 PH 50 Hz
Mains Supply VAC 400 V 3 PH 50 Hz
Rec Permanent Fuse Size A 16 16 16 16 16
Rec Mains Fuse Size A 200 250 315 315 355
Max Permanent Incoming Cable Size mm² 4 mm² terminals
Max Mains Incoming Cable Size mm² Direct to Bus Bar
Control Circuit VAC 24V/230V AC
Evaporator
Pad Heater Rating W 100 100 100 100 100
External Trace Heating
Available (fitted by others) W 500 500 500 500 500
Condenser Fan - Per Fan
Quantity 8 10 10 12 12
Full Load Amps A 1.75 1.75 1.75 1.75 1.75
Locked Rotor Amps A 6.20 6.20 6.20 6.20 6.20
Motor Rating kW 0.98 0.98 0.98 0.98 0.98
Compressor - Per Compressor
Quantity 4 3 + 3 6 3 + 3 6
Motor Rating kW 22.8 18.2 / 15.0 18.2 22.8 / 18.2 22.8
Nominal Run Amps (1) A 40.0 33.0 / 27.0 33.0 40.0 / 33.0 40.0
Sump Heater Rating W 130.0 130.0 / 130.0 130.0 130.0 / 130.0 130.0
Start Amps (2) 320.0 270.0 / 215.0 270.0 320.0 / 270.0 320.0
Type Of Start Direct on line
QUIET DQ UCC300DQ-10/2 UCC330DQ-10/2 UCC360DQ-12/2 UCC400DQ-12/2 UCC450DQ-14/2
All data as above except:
Condenser Fan - Per Fan
Quantity 10 10 12 12 14
Full Load Amps A 1.15 1.15 1.15 1.15 1.15
Locked Rotor Amps A 2.10 2.10 2.10 2.10 2.10
Motor Rating kW 0.70 0.70 0.70 0.70 0.70
SUPER QUIET DSQ
UCC300DSQ-12/2 UCC330DSQ-14/2 UCC360DSQ-14/2 UCC400DSQ-16/2 UCC450DSQ-16/2
All data as above except:
Condenser Fan - Per Fan
Quantity 12 14 14 16 16
Full Load Amps A 0.83 0.83 0.83 0.83 0.83
Locked Rotor Amps A 1.50 1.50 1.50 1.50 1.50
Motor Rating kW 0.32 0.32 0.32 0.32 0.32
OPTIONAL EXTRAS
Power Factor Correction
Nominal Run Amps (1) A 158 180 198 219 237
Maximum Start Amps (2) A 442 435 453 520 540
Recommended Mains Fuse A 200 250 250 250 315
Compressor Nominal Run Amps
- Per Compressor
A 4 x 36 3 x 30 / 3 x 24 6 x 30 3 x 36 / 3 x 30 6 x 36
Electronic Soft-start
Nominal Run Amps (1) A 173 198 216 240 260
Maximum Start Amps (2) A 314 327 345 392 412
Recommended Mains Fuse A 200 250 315 315 355
Single Head Pump (or Run/Standby)
Unit Nominal Run Amps (1) A 189 210 228 252 272
Recommended Mains Fuse A 250 250 315 315 355
Motor Rating kW 5.5 7.5 7.5 7.5 7.5
Full Load Amps
A 11.7 15.2 15.2 15.2 15.2
Larger Single Head Pump (or Run/Standby)
Unit Nominal Run Amps (1) A 197 220 238 261 282
Recommended Mains Fuse A 250 315 315 315 355
Motor Rating kW 11.0 11.0 11.0 11.0 11.0
Full Load Amps
A 21.5 21.5 21.5 21.5 21.5
Twin Head Pump
Unit Nominal Run Amps (1) A 185 209 227 251 275
Recommended Mains Fuse A 250 250 315 315 355
Motor Rating kW 5.5 5.5 5.5 5.5 7.5
Full Load Amps
A 11.7 11.7 11.7 11.7 15.2
Larger Twin Head Pump
Unit Nominal Run Amps (1) A 198 220 238 262 282
Recommended Mains Fuse A 250 315 315 315 355
Motor Rating kW 11.0 11.0 11.0 11.0 11.0
Full Load Amps
A 21.5 21.5 21.5 21.5 21.5
(1) Based at 12/7°C water and 30°C ambient
(2) Starting amps refers to the direct on line connections.
