ULTIMA COMPACT
Chillers
48
Installation Maintenance : 903-129 IM E 10/04/C
Chillers
The serial plate can be located inside Item 24.
UK MAINLAND - Chiller Maintenance Record can be located inside
Item 24.
UCC .. /1 – DUAL CIRCUIT
1 Discharge Line Ball Valve
2 Discharge Schraeder Connection
3 HP Switch
4 Compressor Electrical Terminal Box
5 Oil Level Sight Glass
6 Sump Heater
7 Liquid Line Filter Drier
8 Electronic Expansion Valve (Optional Extras on D Models)
9 Liquid Line Sight Glass
10 Liquid Line
11 Discharge Thermostat Switch
12 Low Pressure Switch
13 Suction Pressure Transducer
14 Suction Port
15 Oil Sump Draw Point
16 Compressor Feet/Resilient Mounts
17 Water Inlet Sensor
18 Evaporator
19 Flow Switch (Optional Extra)
20 Compressor Compartment
21 Evaporator & Optional Pump Compartment
22 Water Inlet Flange Connection
23 Water Outlet Flange Connection
24 Mains Panel
25 Door Interlocking isolator
26 Emergency Stop
27 Incoming Customer Mains Access Points
28 Condenser Coils
29 Unit Controller Panel
30 Fan Contactor MPCB
31 Modulating Head Pressure Controller
32 Compressors MCBs
33 Condenser Fan MPCB
34 Compressor Contactors
35 Isolator
36 Incoming Customer Mains 3 Phase
37 Microprocessor Controller
38 Electronic Expansion Valve Controller (Optional Extra on D
Models)
39 Customer Permanent Supply/Controls Connections
40 EMC Filter
Parts Identification
