ULTIMA COMPACT
Chillers
50
Installation Maintenance : 903-129 IM E 10/04/C
Chillers
The serial plate can be located inside Item 22.
UK MAINLAND - Chiller Maintenance Record can be located inside
Item 22.
UCC .. /2 – DUAL CIRCUIT
1 Water Inlet Sensor
2 Evaporator
3 Flow Switch (Optional Extra)
4 Condenser Fan Contactors
5 Fan Contactor MCB
6 Modulating Head Pressure Controller
7 Compressors MCBs
8 Compressor Contactors
9 Isolator
10 Power Factor Correction (Optional Extra)
11 Evaporator & Optional Pump Compartment
12 Water Inlet Flange Connection
13 Door Interlocking isolator (x 3)
14 Water Outlet Flange Connection
15 Condenser Coils
16 Condenser Fan Mains Panel
17 Mains Panel Circuit 1
18 Mains Panel Circuit 2
19 Bus bar Chamber
20 Incoming Customer Mains Access Points
21 Incoming Customer Mains 3 Phase
22 Unit Controller Panel (Including Serial Plate)
23 Compressor Compartment
24 Discharge Line Ball Valve
25 Low Pressure Switch
26 Suction Pressure Transducer
27 Oil Level Sight Glass
28 Oil Sump Draw Point
29 Discharge Thermostat Switch
30 Discharge Line
31 Suction Port
32 Liquid Line
33 Microprocessor Controller
34 Electronic Expansion Valve Controller (Optional Extra on D
Models)
35 Customer Permanent Supply/Controls Connections
36 EMC Filter
37 Discharge Schraeder Connection
38 HP Switch
39 Compressor Electrical Terminal Box
40 Sump Heater
41 Compressor Feet/Resilient Mounts
42 Electronic Expansion Valve (Optional Extras on D Models)
43 Liquid Line Sight Glass
44 Liquid Line Solenoid Valve (D Models Only)
45 Liquid Line Filter Drier
46 Liquid Line Ball Valve
Parts Identification
