RQT6797
16
Using Graphical User Interface (GUI) screens
[DVD-A] [DVD-V] [VCD] [CD] [MP3]
GUI screens are menus that contain information about the disc or unit.
These menus allow you to perform operations by changing this information.
1
Press [ON SCREEN].
Each time you press the button:
[>Disc information (➡ right)
lv
l Unit information (➡ page 17)
lv
{" Original display
2 [Unit\information\only]
While the leftmost icon is highlighted
Press [3, 4] to select the menu.
Each time you press the button:
Play Menu(------)Picture Menu
ee
uu
Display Menu()Audio Menu
3
Press [2, 1] to select the item.
4
Press [3, 4] to select the setting.
≥Items with “3” or “4” above and below can be changed by
[3, 4].
≥Press [ENTER] if the setting does not change after pressing [3, 4].
≥Some items require different operations. Read the following
explanations.
For your reference
≥Depending on the condition of the unit (playing, stopped, etc.) and the
type of software, there are some items that you cannot select or change.
≥When numbers are displayed (e.g. title No.), the numbered buttons are
also effective for setting. Press [ENTER] to register the setting.
To clear the menus
Press [RETURN] until the menus disappear.
∫ To change the position of the icons
1. Press [2, 1] to select the Bar Position icon
2. Press [3, 4] to move the icons. (There are 5 positions.)
e.g. DVD-Video
e.g. MP3 disc
e.g. Video CD e.g. DVD-Audio
a T: Title number [DVD-V]
Track number [VCD] [CD]
G: Group number [DVD-A] [MP3]
b T: Track number in group [DVD-A] [MP3]
C: Chapter number [DVD-V]
c Time [DVD-A] [DVD-V]
≥Press [3, 4] to show the elapsed play time or remaining time for the
group, track or title (or chapter during program and random play).
≥Select a position to start play by specifying a time with the numbered
buttons and press [ENTER].
Changing the time display [VCD] [CD]
Press [3, 4] to show the elapsed play time, remaining time for the
track, or remaining time for the disc.
Elapsed play time [MP3]
(display only, cannot be changed)
d Soundtrack language [DVD-A] [DVD-V] (➡ page 13)
(See [A] on page 13 for language abbreviations.)
e Audio signal type [DVD-A] [DVD-V] (➡ page 13)
(See [B] on page 13 for details.)
Karaoke vocal on/off (Karaoke DVD only) [DVD-V]
Solo: OFF or ON
Duet: OFF, V1 i V2, V1 or V2
f Subtitle language [DVD-A] [DVD-V] (➡ page 13)
(See [A] on page 13 for language abbreviations.)
Subtitles on/off [DVD-A] [DVD-V]
ON()OFF
Track information on/off [MP3] [CD] (CD text)
ON()OFF
g Angle number [DVD-A] [DVD-V] (➡ page 13)
h Track number in disc [MP3]
i Total number of tracks on disc [MP3]
j Current bitrate [MP3]
k Current sampling frequency [MP3]
l Audio mode [VCD] (➡ page 13)
LR()L()R
^--------------------J
m Menu play [VCD] (with playback control only)
Indicates whether menu play (playback control) is on or off.
n Still picture number [DVD-A]
Selected picture is shown during play.
Common procedures
RETURN
CANCEL
ON SCREEN
3,4,2, 1
ENTER
Numbered
buttons
Disc information
ab c d e f g
ab hi c f
k
128kbps
44.1kHz
j
2
31218
lm
Page
1
1
n
DVD-S830.book 16 ページ ２００２年１０月４日 金曜日 午前１１時７分
