Yamaha DVD-S830 [23/24] Specifications
![Yamaha DVD-S830 [23/24] Specifications](/views2/1041254/page23/bg17.png)
RQT6797
23
Specifications
Signal system: PAL625/50, PAL525/60, NTSC
Operating temperature range: i5 to i35 oC
Operating humidity range: 5 to 90 % RH (no condensation)
Discs played [8 cm or 12 cm]:
(1) DVD-Audio
(2) DVD-Video
(3) DVDiRW/DVDiR
(4) DVD-R/DVD-RW (DVD-Video compatible)
(5) CD-Audio (CD-DA)
(6) Video CD
(7) CD-R/CD-RW (CD-DA, Video-CD formatted discs)
(8) MP3
≥Maximum number of tracks and groups recognizable:
999 tracks and 99 groups
≥Compatible compression rate:
between 32 kbps and 320 kbps
Video output:
Output level: 1 Vp-p (75 ≠)
Output terminal: Pin jack (1 system)/AV
S video output:
Y output level: 1 Vp-p (75 ≠)
C output level:
NTSC; 0.286 Vp-p (75 ≠)
PAL; 0.300 Vp-p (75 ≠)
Output terminal: S terminal (1 system)/AV
RGB video output:
R output level: 0.7 Vp-p (75 ≠)
G
output level: 0.7 Vp-p (75 ≠)
B output level: 0.7 Vp-p (75 ≠)
Output terminal: AV
Audio output:
Output level: 2 Vrms (1 kHz, 0 dB)
Output connector: Pin jack/AV
Number of connectors:
2 channel: 1 system
5.1-channel discrete output (5.1 channel): 1 system
Audio performance:
(1) Frequency response:
≥DVD (linear audio): 2 Hz–22 kHz (48 kHz sampling)
2 Hz–44 kHz (96 kHz sampling)
≥DVD-Audio: 2 Hz–88 kHz (192 kHz sampling)
≥CD audio: 2 Hz–20 kHz
(2) S/N ratio:
≥CD audio: 115 dB
(3) Dynamic range:
≥DVD (linear audio): 102 dB
≥CD audio: 98 dB
(4) Total harmonic distortion:
≥CD audio: 0.0025 %
Digital audio output:
Optical digital output: Optical terminal
Coaxial digital output: Pin jack
Pickup: Wave length: 658 nm/790 nm
Laser power: CLASS 2/CLASS 1
Power supply: AC 220–240 V, 50 Hz
Power consumption: 15 W
Dimensions: 435 (W)k258 (D)k60 (H) mm
Mass: 3.3 kÖ
[Note]
Specifications are subject to change without notice.
Mass and dimensions are approximate.
Power consumption in standby mode: approx. 4 W
Manufactured under license from Dolby Laboratories.
