RQT6797
3
1 To assure the finest performance, please read this manual carefully.
Keep it in a safe place for future reference.
2 Install this sound system in a well ventilated, cool, dry, clean place —
away from direct sunlight, heat sources, vibration, dust, moisture, or
cold. In a cabinet, allow about 2.5cm (1 inch) of free space all around
this unit for adequate ventilation.
3 Locate this unit away from other electrical appliances, motors, or
transformers to avoid humming sounds.
4 Do not expose this unit to sudden temperature changes from cold to
hot, nor locate this unit in an environment with high humidity (i.e., a
room with a humidifier) to prevent condensation inside this unit, which
may cause an electrical shock, fire, damage to this unit, and/or
personal injury.
5 Avoid installing this unit in a location where foreign objects may fall
onto this unit or where this unit may be exposed to liquid dripping or
splashing. On the top of this unit, do not place:
– Other components, as they may cause damage and/or discoloration
on the surface of this unit.
– Burning objects (i.e., candles), as they may cause fire, damage to
this unit, and/or personal injury.
– Containers with liquid in them, as they may fall, spilling the liquid
and causing an electrical shock to the user and/or damage to this
unit.
6 Do not cover this unit with a newspaper, tablecloth, curtain, etc. in
order not to obstruct heat radiation. If the temperature inside this unit
rises, it may cause fire, damage to this unit, and/or personal injury.
7 Do not plug in this unit to a wall outlet until all connections are
complete.
8 Do not operate this unit upside-down. It may overheat, possibly
causing damage.
9 Do not use excessive force on switches, knobs and/or cords.
10 When disconnecting the power cord from the wall outlet, grasp the
plug; do not pull the cord.
11 Do not clean this unit with chemical solvents; this might damage the
finish. Use a clean, dry cloth.
12 Use only the voltage specified on this unit. Using this unit with a higher
voltage than specified is dangerous and may cause fire, damage to
this unit, and/or personal injury. YAMAHA will not be held responsible
for any damage resulting from use of this unit with a voltage other than
as specified.
13 To prevent damage by lightning, disconnect the power cord from the
wall outlet during an electrical storm.
14 Do not attempt to modify or fix this unit. Contact qualified YAMAHA
service personnel when any service is needed. The cabinet should
never be opened for any reason.
15 When not planning to use this unit for long periods of time (i.e.,
vacation), disconnect the AC power plug from the wall outlet.
16 Be sure to read the “Troubleshooting guide” section on common
operating errors before concluding that this unit is faulty.
17 Before moving this unit, press STANDBY/ON to set the unit in standby
mode, then disconnect the AC power plug from the wall outlet.
[NOTE]
Pictures shown maybe different between countries.
Never make or change connections with the power switched on.
When playing DTS encoded CDs, excessive noise will be heard from the
analog stereo outputs. To avoid possible damage to the audio system, the
consumer should take proper precautions when the analog stereo outputs
of the player are connected to an amplification system.
Dear customer
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully.
Caution for AC Mains Lead . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Disc information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Control reference guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Audio connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Video connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting the power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
The remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Basic play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
When a menu screen appears on the television . . . . . . . . . . . . . . . . . 9
Resume function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Starting play from a selected item. . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Skipping items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Fast forward and rewind—SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . 10
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Frame-by-frame viewing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using menus to play MP3 discs and CD text . . . . . . . . . . . . . . . . . . 11
Increasing your enjoyment of movies. . . . . . . . . . . . . . . . . 12
Cinema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Dialogue Enhancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Advanced Surround. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing soundtracks, subtitles and angles. . . . . . . . . . . . . . . . . . . 13
4:3 TV Zoom function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Convenient features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting groups to play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting still pictures—Page Skip . . . . . . . . . . . . . . . . . . . . . . . . . . 14
To enjoy even higher quality sound—VIDEO OFF . . . . . . . . . . . . . . 14
A-B repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Random play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Program play/All group play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using Graphical User Interface (GUI) screens . . . . . . . . . . 16
Common procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Disc information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Unit information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Common procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Entering a password (Ratings) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Digital output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Speaker setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
CAUTION: READ THIS BEFORE OPERATING
YOUR UNIT.
The unit is not disconnected from the AC power source as long as it
is connected to the wall outlet,even if this unit itself is turned off.This
state is called the standby mode.In this state,this unit is designed to
consume a very small quantity of power.
Table of contents
Getting started
Basic operations
Advanced operations
Reference
