[TP-LINK]: start

Start . . . . . . . .

◀

* * * * * * * * * * * * * * * * * *

User Access Login

* * * * * * * * * * * * * * * * *

User:

When you forget the login user name and password, you can enter reset command after entering

into bootUtil menu to reset the system. The system will be restored to the factory default settings,

and the default login user name and password are both admin.

Return to CONTENTS

232
