Tp-Link TL-SG5412F [84/257] Configuration procedure

Primary

VLAN: Specify the Primary VLAN the port belongs to.

Secondary VLAN: Specify the Secondary VLAN the port belongs to.

 Private VLAN Port Table

Port ID: Displays the port number.

Port Type: Displays the corresponding Port Type.

Operation: Click Remove button to delete the port.

Note:

1. A Host Port can only join to a Private VLAN.

2. A Promiscuous Port can only join to a Primary VLAN.

3. If you want to add a Promiscuous port to different Private VLANs with the same Primary VLAN,

you need to add the Promiscuous port to any one of these Private VLANs.

Configuration Procedure:

Step Operation Description

1 Create Private VLAN. Required. On the VLAN→Private VLAN→PVLAN page,

Enter the Primary VLAN and Secondary VLAN, and then

click the Create button.

2 Add ports to Private VLAN Required. On the VLAN→Private VLAN→Port Configure

page, select the desired ports and configure the port types

and click the Add button.

3 Modify VLAN. Optional. On the VLAN→Private VLAN→PVLAN page,

select the desired Private VLAN and do the modification,

then click the Apply button to modify the information of the

corresponding VLAN.

4 Delete VLAN. Optional. On the VLAN→Private VLAN→PVLAN page,

select the desired entry to delete the corresponding VLAN

by clicking the Delete button.

6.8 Application Example for Private VLAN

 Network Requirements

 Switch A is connecting to Switch B, Switch B is connecting to Switch C;

 Switch B is connecting to PC1, PC2 and PC3;

 Switch C is connecting to PC4, PC5 and PC6;

 PCs in different VLANs cannot communicate with each other;

 For Switch A, packets from Switch B and Switch C have no VLAN tags. Switch A needs not

consider the VLANs of Switch B and Switch C.
