19
L2 Lite Managed Switch
Port SettingsFigure 5-7
Type the User name and Password in the Hyper Terminal window, the factory default 6.
value for both of them is admin. The DOS prompt” TP-LINK>” will appear after
pressing the Enter button as Figure 5-8 shown. It indicates that you can use the CLI
now.
Log in the SwitchFigure 5-8
Logon by Telnet
■
To log on to the switch by a Telnet connection, please take the following steps:
Make sure the switch and the PC are in the same LAN.1.
Click Start2.
→
Run to open the Run window.
Configuration
