L2 Lite Managed Switch

Type the User name and Password (the factory default value for both of them is 5.

admin) and press the Enter button, then you can use the CLI now, which is shown as

Figure 5-12.

For detailed CLI configuration instructions, please refer to the CLI Reference Guide on

the resource CD.

Configuration
