Chapter Introduction
Chapter 4 System This module is used to configure system properties of the switch.
Here mainly introduces:
System Info: Configure the description, system time and network
parameters of the switch.
User Manage: Configure the user name and password for users
to log on to the Web management page with a certain access
level.
System Tools: Manage the configuration file of the switch.
Access Security: Provide different security measures for the
login to enhance the configuration management security.
Chapter 5 Switching This module is used to configure basic functions of the switch. Here
mainly introduces:
Port: Configure the basic features for the port.
LAG: Configure Link Aggregation Group. LAG is to combine a
number of ports together to make a single high-bandwidth data
path.
Traffic Monitor: Monitor the traffic of each port
MAC Address: Configure the address table of the switch.
Chapter 6 VLAN This module is used to configure VLANs to control broadcast in
LANs. Here mainly introduces:
802.1Q VLAN: Configure port-based VLAN.
Chapter 7 Spanning Tree This module is used to configure spanning tree function of the
switch. Here mainly introduces:
STP Config: Configure and view the global settings of spanning
tree function.
Port Config: Configure CIST parameters of ports.
MSTP Instance: Configure MSTP instances.
STP Security: Configure protection function to prevent devices
from any malicious attack against STP features.
Chapter 8 Multicast This module is used to configure multicast function of the switch.
Here mainly introduces:
IGMP Snooping: Configure global parameters of IGMP Snooping
function, port properties, VLAN and multicast VLAN.
Multicast IP: Configure multicast IP table.
Multicast Filter: Configure multicast filter feature to restrict users
ordering multicast programs.
Packet Statistics: View the multicast data traffic on each port of
the switch, which facilitates you to monitor the IGMP messages
in the network.
Chapter 9 QoS This module is used to configure QoS function to provide different
quality of service for various network applications and
requirements. Here mainly introduces:
DiffServ: Configure priorities, port priority, 802.1P priority and
DSCP priority.
Bandwidth Control: Configure rate limit feature to control the
traffic rate on each port; configure storm control feature to filter
broadcast, multicast and UL frame in the network.
3
Содержание
- Gigabit smart switch 1
- Tl sg2216 tl sg2424 1
- Ce mark warning 2
- Copyright trademarks 2
- Fcc statement 2
- Safety notices 2
- Package contents 8
- Chapter 1 about this guide 9
- Conventions 9
- Intended readers 9
- Overview of this guide 9
- Appearance description 12
- Chapter 2 introduction 12
- Front panel 12
- Main features 12
- Overview of the switch 12
- Rear panel 13
- Chapter 3 login to the switch 15
- Configuration 15
- Chapter 4 system 17
- System info 17
- System summary 17
- Device description 19
- System time 19
- Daylight saving time 20
- System ip 21
- User manage 22
- User table 22
- User config 23
- Config restore 24
- System tools 24
- Config backup 25
- Firmware upgrade 25
- System reboot 26
- System reset 26
- Access control 27
- Access security 27
- Chapter 5 switching 29
- Port config 29
- Port mirror 30
- The following entries are displayed on this screen 31
- Port security 32
- Port isolation 34
- Lag table 35
- Static lag 36
- Traffic monitor 37
- Traffic summary 37
- Traffic statistics 39
- Mac address 40
- Address table 41
- Static address 42
- Dynamic address 43
- Filtering address 45
- Chapter 6 vlan 47
- Q vlan 48
- Vlan config 50
- Port config 52
- Configuration procedure 53
- Application example for 802 q vlan 54
- Chapter 7 spanning tree 56
- Stp config 61
- Port config 63
- Stp summary 63
- Mstp instance 65
- Region config 65
- Instance config 66
- Instance port config 67
- Global configuration procedure for spanning tree function 69
- Port protect 69
- Stp security 69
- Application example for stp function 72
- Tc protect 72
- Chapter 8 multicast 76
- Igmp snooping 78
- Snooping config 79
- Port config 80
- Vlan config 81
- Configuration procedure 83
- Multicast vlan 83
- Application example for multicast vlan 85
- Configuration procedure 85
- Multicast filter 86
- Ip range 87
- Port filter 87
- Configuration procedure 89
- Packet statistics 89
- Chapter 9 qos 91
- Diffserv 94
- Port priority 94
- Configuration procedure 95
- Schedule mode 95
- Configuration procedure 96
- Dscp priority 96
- P priority 96
- Configuration procedure 97
- Bandwidth control 98
- Rate limit 98
- Storm control 99
- Chapter 10 snmp 101
- Global config 103
- Snmp config 103
- Snmp group 104
- Snmp view 104
- Snmp user 106
- Snmp community 107
- Configuration procedure 109
- Notification 110
- History control 112
- Alarm config 113
- Event config 113
- Chapter 11 maintenance 116
- Cpu monitor 116
- System monitor 116
- Memory monitor 117
- Log table 118
- Local log 119
- Remote log 119
- Backup log 120
- Cable test 121
- Device diagnose 121
- Loopback 122
- Network diagnose 122
- Tracert 123
- Appendix a specifications 125
- Appendix b configuring the pcs 126
- Appendix c glossary 128
