Tp-Link TL-SG2424 [8/130] Package contents

Package Contents

The following items should be found in your box:

 One Gigabit Smart Switch

 One power cord

 Two mounting brackets and other fittings

 Installation Guide

 Resource CD for TL-SG2216/TL-SG2424 Switch, including:

 This User Guide

 Other Helpful Information

Note:

Make sure that the package contains the above items. If any of the listed items are damaged or

missing, please contact with your distributor.
