Address Mode: Select the mode to obtain IP Address for the switch.

 Static IP: When this option is selected, you should enter IP

Address, Subnet Mask and Default Gateway manually.

 DHCP: When this option is selected, the switch will obtain

network parameters from the DHCP Server.

 BOOTP: When this option is selected, the switch will obtain

network parameters from the BOOTP Server.

Management VLAN: Enter the ID of management VLAN, the only VLAN through which

you can get access to the switch. By default VLAN1 owning all the

ports is the Management VLAN and you can access the switch via

any port on the switch. However, if another VLAN is created and

set to be the Management VLAN, you may have to reconnect the

management station to a port that is a member of the

Management VLAN.

IP Address: Enter the system IP of the switch. The default system IP is

192.168.0.1 and you can change it appropriate to your needs.

Subnet Mask: Enter the subnet mask of the switch.

Default Gateway: Enter the default gateway of the switch.

Note:

1. Changing the IP address to a different IP segment will interrupt the network communication, so

please keep the new IP address in the same IP segment with the local network.

2. The switch only possesses an IP address. The IP address configured will replace the original

IP address.

3. If the switch gets the IP address from DHCP server, you can see the configuration of the

switch in the DHCP server; if DHCP option is selected but no DHCP server exists in the

network, a few minutes later, the switch will restore the setting to the default.

4. If DHCP or BOOTP option is selected, the switch will gets network parameters dynamically

from the Internet, so IP address, subnet mask and default gateway can not be configured.

5. By default, the default IP address is 192.168.0.1.

4.2 User Manage

User Manage functions to configure the user name and password for users to log on to the Web

management page with a certain access level so as to protect the settings of the switch from being

randomly changed.

The User Manage function can be implemented on User Table and User Config pages.

4.2.1 User Table

On this page you can view the information about the current users of the switch.

Choose the menu System→User Manage→User Table to load the following page.
