Features:
Specifications:
Standards
Basic Function
Wave Length
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Full Duplex Flow Control (IEEE 802.3x)
Extends ber distance up to 0.55km using 50/125um ber, 0.22km using 62.5/125um
ber
850nm
1 1000Mbps SC port
1 1000Mbps RJ45 port (Auto MDI/MDIX)
1000BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-FX: Multi-mode Fiber
PWR, LINK, RX
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
The MC200CM media converter converts 1000BASE-SX fiber to 1000Base-T copper media or vice versa. It is
designed for use with 850nm multi-mode fiber cable utilizing the SC-Type connector, transmitting data up to
0.55 kilometers away. What's more, MC200CM can work as a stand alone device (no chassis required) or with
TP-LINK´s 19” system chassis.
Works at 1000Mbps in Full-Duplex mode for both TX port and FX port
Supports Auto MDI/MDIX for TX port
Provides switch configuration of Force /Auto transfer mode for FX port
Extends fiber distance up to 0.55km
Easy-to-view LED indicators provide status to monitor network activity easily
MC200CM
