www.tp-link.com
Page 7
Features:
Specifications:
Standards
Basic Function
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3u, IEEE 802.3x
Half/Full-Duplex transfer mode for TX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends ber distance up to 20km
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
1 100Mbps SC port
1 100Mbps RJ45 port (Auto MDI/MDIX)
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-FX: Single-mode Fiber
PWR, SPD, LFP, FDX/Col, Link/Act
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
The MC110CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice
versa. It’s designed for use with single-mode fiber cable utilizing the SC-Type connector, transmitting data up
to 20 kilometers. What’s more, MC110CS can work as a stand alone device (no chassis required) or with
TP-LINK’s 19’’ system chassis, and is equipped with Link Fault Pass Through which minimizes the loss caused by
link failure.
Auto negotiation of 10/100Mbps and Auto MDI/MDIX for TX port
Provide switch configuration of Half-Duplex / Full-Duplex transfer mode for TX port
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
Extend fiber distance up to 20km
Easy-to-view LED indicators provide status to monitor network activity easily
MC110CS
