www.tp-link.com
Page 8
Features:
Specifications:
Standards
Basic Function
Interface
Wave Length
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3u, IEEE 802.3x
Half/Full-Duplex transfer mode for TX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends ber distance up to 20km
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
1 100Mbps SC port
1 100Mbps RJ45 port (Auto MDI/MDIX)
TX: 1550nm
RX: 1310nm
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-FX: Single-mode Fiber
PWR, SPD, LFP, FDX/Col, Link/Act
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
The MC111CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice
versa. It’s designed for use with single-mode fiber cable utilizing the SC-Type connector. Adopting WDM
technology, MC111CS takes only one fiber to transmit and receive data, which saves you half of the cabling
cost. On this fiber, it works at 1550nm on transferring data and at 1310nm on receiving data. So the other end
device cooperating with the MC111CS will work at 1310nm on transferring data and at 1550nm on receiving
data. Another of TP-LINK’s media converters, the MC112CS is just one example of potential devices with which
to cooperate with the MC111CS.Moreover, MC111CS can work as a stand alone device (no chassis required) or
with TP-LINK’s 19’’ system chassis, and is equipped with Link Fault Pass Through which minimizes the loss
caused by link failure.
Auto negotiation of 10/100Mbps and Auto MDI/MDIX for TX port
Provide switch configuration of Half-Duplex / Full-Duplex transfer mode for TX port
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
Adopts WDM technology, transmitting and receiving data on one single fiber
Extend fiber distance up to 20km
Easy-to-view LED indicators provide status to monitor network activity easily
MC111CS
