TL-WPA281/TL-WPA271 Wireless N Powerline Extender

Chapter 2 Hardware Connection

2.1 Before You Begin

Please read this User Guide carefully before installing and using the equipment. The operating distance

or range of your wireless connection varies significantly based on the physical placement of the

Powerline Extender. Factors that can weaken signals by getting in the way of your network’s radio

waves are metal appliances or obstructions, and walls. Typical ranges vary based on the types of

materials and background RF (radio frequency) noise in your home or office.

For best performance of your wireless network, you are suggested to place your Powerline Extender:

1). Near the center of the area in which your wireless stations will operate.

2). In an elevated location such as a high shelf.

3). Away from the potential sources of interference, such as PCs, microwaves, and cordless phones.

4). With the Antenna in the upright position.

5). Away from large metal surfaces.

Failure to follow these guidelines can result in significant performance degradation or inability to

wirelessly connect to the Powerline Extender.

)

Note:

Take notes that this Wireless N Powerline Extender works in pairs or with another powerline adapter.

You need to plug the Wireless N Powerline Extender into a power outlet; you will also need another

Wireless N Powerline Extender or Powerline Ethernet Adapter connected to your Cable/xDSL

broadband (Ethernet port) in order to extend your broadband connection or Internet surfing. With clean

powerline, the distance between two Powerline Ethernet Adapters can reach 300 meters, but the actual

distance may vary due to the environment.

Section below describes the Wireless N Powerline Extender’s LED indicators, physical interface and

hardware connection mechanism.

2.2 LED Indicator

The LED indicator displays information about the device’s status.
