TD-W8901GB 54M Wireless ADSL2+ Modem Router User Guide

Chapter 4 Software Configuration

This User Guide recommends using the “Quick Installation Guide” for first-time installation. For

advanced users, if you want to know more about this device and make use of its functions

adequately, maybe you will get help from this chapter to configure the advanced settings through

the Web-based Utility.

After your successful login, you can configure and manage the device. There are main menus on

the top of the Web-based Utility; submenus will be available after you click one of the main menus.

On the center of the Web-based Utility, there are the detailed configurations or status information.

To apply any settings you have altered on the page, please click the SAVE button.

4.1 Status

Choose “Status”, you can see the next submenus: Device Info, System Log and Statistics.

Click any of them, and you will be able to configure the corresponding function.

Figure 4-1

Click any of them, and you will be able to view the corresponding information.

4.1.1 Device Info

Choose “Status→Device Info” menu, and you will be able to view the device information,

including LAN, WAN and ADSL. The information will vary depending on the settings of the Router

configured on the Interface Setup screen.
