TD-W8901GB 54M Wireless ADSL2+ Modem Router User Guide

1). Select an IP Address from the drop-down list.

2). Enter the MAC Address of the client in the table.

• DNS Relay: If you want to disable this feature, you just need to set both Primary and

secondary DNS IP to 0.0.0.0. If you want to use DNS relay, you can setup DNS server IP

to 192.168.1.1 on their Computer. If not, the device will perform as no DNS relay.

• Primary DNS Server: Type in your preferred DNS server.

• Secondary DNS Server: Type in your preferred DNS server.

• Current Pool Summary: Click the button, then you can view the IP addresses that the

DHCP Server gives out.

)

Note:

If Use Auto Discovered DNS Server Only is selected in DNS Relay, this router will accept the

first received DNS assignment from one of the PPPoA, PPPoE or MER/DHCP enabled PVC(s)

during the connection establishment. If Use User Discovered DNS Server Only is selected in

DNS Relay, it is necessary for you to enter the primary and optional secondary DNS server IP

addresses. After type in the address, click SAVE button to save it and invoke it.

¾ DHCP Relay: Select Relay, then you will see the next screen (shown in Figure 4-13), and the

Router will work as a DH

CP Relay. A DHCP relay is a computer that forwards DHCP data

between computers that request IP addresses and the DHCP server that assigns the

addresses. Each of the device's interfaces can be configured as a DHCP relay. If it is enabled,

the DHCP requests from local PCs will forward to the DHCP server runs on WAN side. To

have this function working properly, please run on router mode only, disable the DHCP server

on the LAN port, and make sure the routing table has the correct routing entry.

Figure 4-13

• DHCP Server IP for Relay Agent: Enter the DHCP server IP Address runs on WAN

side.

)

Note:

If you select Disabled, the DHCP function will not take effect.

4.3.3 Wireless

Choose “Interface Setup→Wireless” menu, and you will see the Wireless screen (shown in

Figure 4-14 ). Please configure the parameters for wireless according to the

descriptions below.
