TL-R480T SMB Broadband Router User Guide

from lightning.

2.4 Connecting the Router

Before you install the router, you should connect your PC to the Internet through your broadband

service successfully. If there is any problem, please contact with your ISP for help. After that,

please install the router according to the following steps. Don't forget to pull out the power plug

and keep your hands dry.

1. Power off your PC(s), Cable/DSL modem, and the router.

2. Connect the PC(s) and all Switches/Hubs on your LAN to the LAN Ports on the router, shown

in figure 2-3.

3. Connect the DSL/Cable modem to the WAN port on the router, shown in figure 2-3.

4. Connect the AC power adapter to the AC power socket on the router, and the other end into

an electrical outlet. The router will start to work automatically.

5. Power on your PC(s) and Cable/DSL modem.

Figure 2-3
