TL-R480T SMB Broadband Router User Guide
67
1) To access the router, you will type your router's WAN IP address into your browser's
address (in IE) or Location (in Navigator) box, followed by a colon and the custom port
number. For example, if your Router's WAN address is 202.96.12.8, and the port number
you use is 8080, please enter http://202.96.12.8:8080 in your br
owser. Later, you may be
asked for the router's password. After successfully entering the username and password,
you will be able to access the router's web-based utility.
2) Be sure to change the router's default password to a very secure password.
4.13.9 Statistics
Choose menu “System Tools→Statistics”, you can view the statistics of the Router. This screen
(shown in Figure 4-74 ) displays the network traffic of each PC on LAN, including tot
al traffic and
current traffic of the last “Packets Statistic interval” seconds.
Figure 4-74
¾ Current Statistics Status - Enable or Disable the statistics function. The default status is
disabled. Click the Enable button to use the function. Click the Disable button to disable the
function.
¾ Packets Statistics Interval - The default value is 10. Select a value between 5 and 60
seconds in the pull-down list. The Packets Statistic interval value indicates the time section of
the packets statistic.
¾ Sort Rules - Select the rule for displaying the traffic information.
¾ Statistics Table - This table displays the statistics information about the traffic.
IP Address
MAC Address
The IP address whose statistics information are displayed
