TL-R480T SMB Broadband Router User Guide
3
There are two ways to reset the router:
Method one: Use the Factory Defaults function on System Tools -> Factory Defaults page in
the router's Web-based Utility.
Method two: Use the Factory Default Reset button: Press the Reset button for five seconds and
then wait for the router to reboot.
)
Note:
Ensure the router is powered on before it restarts completely.
¾ WAN: One RJ45 port for connecting the router to a cable, DSL modem or Ethernet
¾ LAN: Eight 10/100/1000Mbps RJ45 port for connecting the router to the local PCs
2.1.2 The Rear Panel
The rear panel of the TL-R480T only features a power receptacle, which is an AC power
receptacle. Connect the female of the power cord head here, and the male head to the AC power
outlet.
220V~ 50Hz 0.1A
Figure 2-2
2.2 System Requirements
¾ Broadband Internet Access Service (DSL/Cable/Ethernet)
¾ One DSL/Cable modem that has an RJ45 connector (It’s not necessary if you connect the
router to Ethernet)
¾ Each PC on the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45
connectors
¾ TCP/IP protocol must be installed on each PC
¾ Web browser, such as Microsoft Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later
2.3 Installation Environment Requirements
¾ Not in direct sunlight or near a heater or heating vent
¾ Not cluttered or crowded. There should be at least 2 inches (5 cm) of clear space on all sides
of the router
¾ Well ventilated (especially if it is in a closet)
¾ Operating temperature: 0℃~40℃ (32℉~104℉)
¾ Operating Humidity: 10%~90%RH, Non-condensing
)
Note:
Do not use this product near water, for example, in a wet basement or near a swimming pool.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock
