DES-1210G Fast Ethernet/Gigabit Ethernet Switch User’s Guide
19
A
7 T
ECHNICAL
S
PECIFICATIONS
General
Standards: IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3z 1000BASE-SX Gigabit Ethernet
IEEE 802.3x Flow Control
ANSI/IEEE Std 802.3 NWay auto-negotiation
Protocol: CSMA/CD
Data Transfer Rate: Ethernet: Fast Ethernet:
10 Mbps (half duplex) 100Mbps (half duplex)
20 Mbps (full duplex) 200Mbps (full duplex)
Gigabit Ethernet:
2000 Mbps (full-duplex only)
Topology: Star
Network Cables:
10BaseT:
100Base-TX:
1000BASE-SX:
UTP Category 3,4,5 (100 m)
EIA/TIA- 568 100-ohm STP (100 m)
UTP Cat. 5 (100 m)
EIA/TIA-568 100-ohm STP (100 m)
50/125µm Multimode Fiber-optics (550 meters max.)
62.5/125µm Multimode Fiber-optics (275 meters max.)
Number of Ports: 8 x 10/100 Mbps MDI-X ports
(including port 1x shared MDI-II)
2 x 1000 Mbps SX multifiber ports
Media Interface
Exchange:
MDI-II RJ-45 shared with port 1x
Physical and Environmental
AC input
100 - 240 VAC, 50 - 60 Hz , 1.A Max,
Internal universal power supply
Power Consumption: 12 watts maximum
DC fans: 1 built-in 40 x 40 mm fan
Operating
Temperature:
32 ° ~ 122 °F (0 ° ~ 50 °C)
Storage
Temperature:
-13 ° ~ 131 °F (-25 ° ~ 55 °C)
Humidity: 5% ~ 95% non-condensing
Dimensions: 32.4cm x 23.1cm x 4.4cm
