D-Link DES-1210G [28/36] Performance
![D-Link DES-1210G [28/36] Performance](/views2/1043032/page28/bg1c.png)
DES-1210G Fast Ethernet/Gigabit Ethernet Switch User’s Guide
20
Physical and Environmental
Weight: 2.65 Kg
EMI:
CE Class A, C-Tick Class A, FCC Class A, VCCI Class A, BSMI class A
Safety: UL/CUL, TUV/GS
Performance
Transmission Method: Store-and-forward
RAM Buffer: 6 Mb bytes per device
MAC Address Table: 17 Kb entries per device
Packet Filtering/Forwarding
Rate:
14,880 pps per port (for 10Mbps)
148,810 pps per port (for 100Mbps)
1,488,100 pps per port (for 1000Mbps)
