![D-Link DES-1210G [31/36] Base sx fiber optic cable maximum lengths](/views2/1043032/page31/bg1f.png)
DES-1210G Fast Ethernet/Gigabit Ethernet Switch User’s Guide
23
C
1000 BASE-SX Fiber Optic Cable –Maximum Lengths
Use the following table to as a guide for the maximum lengths for 1000BASE-SX cable.
Standard
Media Type
MHz/km
Rating
Maximum
Distance
1000BASE-SX
50/125µm
Multimode Fiber
400 500 Meters
50/125µm
Multimode Fiber
500 550 Meters
62.5/125µm
Multimode Fiber
160 220 Meters
62.5/125µm
Multimode Fiber
200
275 Meters
